AJAX LightSwitch Jeweller User Manual

Smart touch light switch
Hide thumbs Also See for LightSwitch Jeweller:

Advertisement

Quick Links

Download this manual
LightSwitch (Crossover) Jeweller user
LightSwitch Jeweller is a smart touch light switch for indoor installation. It can
replace any mechanical or touch switch, with the product line offering one-gang
and two-gang regular, two-way, and crossover versions. Devices can be
combined as a set with other Ajax smart switches and/or outlets* and installed
horizontally or vertically into one Frame side by side.
Use the online
Combine devices into a frame, pick the color, and download your configuration as PDF.
LightSwitch is installed without changing the electrical wiring at the facility. The
device does not require a neutral wire, operates only from the power phase, and
features a standard European form factor (55).
LightSwitch operates as a part of the Ajax system, communicating with the hub
using two secure protocols. The light switch uses
manual
Updated July 24, 2024
Ajax switches and outlets configurator
to assemble your custom set.
Jeweller
to transmit alarms

Advertisement

loading
Need help?

Need help?

Do you have a question about the LightSwitch Jeweller and is the answer not in the manual?

Questions and answers

Related Manuals for AJAX LightSwitch Jeweller

Summary of Contents for AJAX LightSwitch Jeweller

  • Page 1 Updated July 24, 2024 LightSwitch Jeweller is a smart touch light switch for indoor installation. It can replace any mechanical or touch switch, with the product line offering one-gang and two-gang regular, two-way, and crossover versions. Devices can be combined as a set with other Ajax smart switches and/or outlets* and installed horizontally or vertically into one Frame side by side.
  • Page 2 LightSwitch is a prefabricated smart light switch. All switch components are purchased separately. Elements are connected mechanically without the need for tools. There are two LightSwitch formats in the Ajax product line: single and combined. Combined switches can be horizontal and vertical.
  • Page 3 Combined switch A combined switch consists of several LightCore relays and touch-sensitive panels installed into one Frame with the appropriate number of seats. Relay Plastic frames Touch-sensitive panels Side touch-sensitive panels are installed on the right and left or on the top and bottom sides of the frame, while central touch-sensitive panels are installed in the center.

  • Page 4: Functional Elements

    In the switch settings in Ajax apps, the color of LightSwitch can be changed. The color in the app does not have to match the color of the installed panel. A PRO or a user with admin rights can change the panel color anytime. For example, if the installer has replaced the touch-sensitive panel or a user wishes to set different colors for the switches in the app to distinguish them.
  • Page 5 SoloButton (1-gang) CenterButton (1-gang) CenterButton (1-gang) vertical SideButton (1-gang) SideButton (1-gang) vertical Frames Frames are available with 2 to 5 seats in horizontal and vertical orientations. These frames are used when installing multiple LightSwitch and/or Outlet devices* in a row. * Combinations with smart outlets are available only in a horizontal orientation.

  • Page 6: Operating Principle

    Frame (3 seats) vertical Frame (4 seats) Frame (4 seats) vertical Frame (5 seats) Frame (5 seats) vertical Operating principle 00:00 00:12 LightSwitch is a smart touch light switch. It can control the lighting in three ways: manually, through smartphone and PC apps, and using automation scenarios LightSwitch is installed without changing the electrical wiring at the facility.
  • Page 7 If necessary, a PRO or a user with admin rights can disable the backlight in Ajax apps The product line includes one-gang and two-gang regular, two-way, and crossover light switches:...

  • Page 8: Manual Control

    “vertical” in the name. Use the online Ajax switches and outlets configurator to assemble your custom set. Combine devices into a frame, pick the color, and download your configuration as PDF.

  • Page 9: Remote Control

    Ajax apps Open the Ajax app and click on the switch in the LightSwitch field in the Devices menu: the state of the switch contacts will change to the opposite, and the lighting will be switched off/on. This way, system users can, for example, switch...
  • Page 10 Lighting control is also available in the Control menu. To do this, go to the Control menu and swipe up. All control devices added to the hub will appear in the list. Click on the switch in the LightSwitch field, and the state of the device contacts will change to the opposite.

  • Page 11: Operation Modes

    LightSwitch supports the following types of scenarios: By alarm By arming/disarming By schedule By Button press By temperature By humidity By CO concentration By touching LightSwitch Scenarios by humidity and CO concentration are available when LifeQuality is added to the system. The system does not allow creating sequences of scenarios when the execution of one scenario activates the following one.
  • Page 12 Temperature protection triggers if the temperature of the switch exceeds +60 °C. If this protection triggers, LightSwitch turns off the power and sends a notification to Ajax apps. The power supply is restored automatically when the temperature of the switch returns to normal.
  • Page 13 Detection of lighting devices with insufficient power LightSwitch continuously checks its power supply parameters. If LightSwitch controls the power of a lighting device with insufficient power (up to 7 W), the system will notify users. In this case, it is necessary to replace the lighting device with a similar one with higher capacity or to connect a bundled capacitor in parallel with the lighting device.

  • Page 14: Firmware Update

    Firmware updates are not available for LightSwitch when operating via Hub Plus Sending events to the monitoring station The Ajax system can transmit alarms to both PRO Desktop monitoring app and the central monitoring station (CMS) in the formats of SurGard (Contact ID), SIA...

  • Page 15: Selecting The Installation Site

    When an alarm is received, the operator at the security company’s CMS knows what happened and precisely where to dispatch a rapid response team. The addressability of Ajax devices allows sending events to PRO Desktop or the CMS, including the device type, its name, security group, and virtual room. Note that the list of transmitted parameters may vary depending on the CMS type and the selected communication protocol for it.

  • Page 16: Installation

    on the Devices tab indicates the signal strength: three bars — excellent signal strength; two bars — good signal strength; one bar — low signal strength, stable operation is not guaranteed; crossed out icon — no signal. Check the Jeweller and Wings signal strength before the final installation. With a signal strength of one or zero bars, we do not guarantee stable operation of the device.
  • Page 17 Only a qualified electrician or installer should install LightSwitch. Do not switch on the power at the switches before installing the touch-sensitive panels. Also, do not try to register the device before installing the touch-sensitive panel, as it contains antennas needed to communicate with the hub.
  • Page 18 LightSwitch (Crossover) Jeweller can control 7 to 600 W lighting devices. The kit includes a capacitor connected in parallel with the lighting device for low- power lamps. Learn more about bundled capacitor When LightSwitch (Crossover) Jeweller is connected to the same or other LightSwitch devices in one electric circuit, the minimum required power of a lighting device increases to 1 W per each additional LightSwitch.
  • Page 19 3. Select a space or create a new one. What is a space How to create a space The space functionality is available for apps of such versions or later: Ajax Security System 3.0 for iOS;...
  • Page 20 Ajax Security System 3.0 for Android; Ajax PRO: Tool for Engineers 2.0 for iOS; Ajax PRO: Tool for Engineers 2.0 for Android; Ajax PRO Desktop 4.0 for macOS; Ajax PRO Desktop 4.0 for Windows. 4. Add at least one virtual room 5.
  • Page 21 If the maximum number of devices is added to the hub, you will get a notification about exceeding the device limit when you try to add the switch in the Ajax app. The number of devices that can be added to the hub depends on the...

  • Page 22: Functionality Testing

    After installation, test the operation of the switch: how it responds to touch and whether it switches on/off the light. The Ajax system provides several tests to select the location of devices correctly. Tests do not start immediately. However, the waiting time does not exceed the duration of one “hub —...
  • Page 23 Icons in the Ajax app display some of LightSwitch states. Icons can be checked in the Devices tab. Icon Meaning Jeweller Signal Strength displays the signal strength between the hub and the switch. Learn more radio signal range The switch communicates with the hub via a extender Temperature protection was activated.
  • Page 24 The states in the Ajax app provide information about LightSwitch and its operating parameters. To view the states: 1. Open the Ajax app. 2. Select the required hub. 3. Go to the Devices tab. 4. Select LightSwitch in the list.
  • Page 25 Signal strength between the switch and the hub (or range extender) via the Jeweller channel. Recommended values: 2–3 bars. Jeweller is a protocol for transmitting Jeweller Signal Strength LightSwitch events and commands. Learn more Connection status between the switch and the hub (or range extender): Online —...
  • Page 26 Connection status on the Wings channel between the hub or the range extender and the device: Online — the device is connected to the hub or the range extender. Normal state. Offline — the device is not connected to the Connection via Wings hub or the range extender.
  • Page 27 Maximum Higher sensitivity ensures contactless operation, while lower values might require slightly touching the switch button. The status of the switch frame backlight is displayed as follows: On — the LED frame is backlit when the Backlight switch is off. Off —...
  • Page 28 Device No. Number of the switch loop (zone). Settings To change the switch settings: 1. Open the Ajax app. 2. Select the required hub. 3. Go to the Devices tab. 4. Select LightSwitch in the list.
  • Page 29 . Set the required settings. 7. Click Back to save the new settings. Settings Meaning LightSwitch name. Displayed in the text of SMS and events feed notifications. To change the switch name, click on the text Name field. The name can contain up to 12 Cyrillic characters or up to 24 Latin symbols.
  • Page 30 When connection lost/restored — enable the option to be notified in the app when the device goes offline and when the communication with the hub is restored. This option is enabled by default. When turned on/off — enable the option to receive notifications in the app about switching on/off the light with the switch.
  • Page 31 Switches the device to the Wings signal strength test mode. Wings Signal Strength Test Learn more User Guide Opens the switch user manual in the Ajax app. Permanent Deactivation Allows to deactivate the device without removing it from the system. Two options are available: No —...

  • Page 32: Led Indication

    LightSwitch will retain its state at the time of deactivation: on/off. Learn more Allows the user to disable events of the device until the first disarm. Two options are available: No — the device operates in normal mode. Entirely — the device is completely excluded from system operations until the first One-Time Deactivation disarm.
  • Page 33 The backlight can be turned off in the Ajax app if necessary. If the temperature protection of LightSwitch has been triggered or the touch- sensitive panel removed, the switch flashes red every second. To inform you that LightSwitch is not paired with the hub, it flashes green every second for one minute: when you connect LightSwitch to the power supply the first time;...
  • Page 34 A device with insufficient power is connected. An insufficient power supply is detected. There is no communication between LightSwitch and the hub (or range extender). What to do in case of loss of communication with the device LightSwitch may lose communication with the hub for the following reasons: Power is no longer supplied.

  • Page 35: Maintenance

    Combine devices into a frame, pick the color, and download your configuration as PDF. Warranty The warranty for the products of the Limited Liability Company “Ajax Systems Manufacturing” is valid for 2 years after purchase.
  • Page 36 If the device does not operate properly, we recommend contacting support service first, as in most cases, technical issues can be resolved remotely. Warranty obligations User Agreement Contact Technical Support: email Telegram Subscribe to the newsletter about safe life. No spam Email Subscribe...
