Taurus Prone Leg Curl IFP Assembly And Operating Instructions Manual page 28

Handle Frame ASSY (5)
Grade No. Part no.
5.1 IFP16040500
5.2 FE97031800
5.3 V39600
5.4 V39500
5.5 YZGB7710-32*3.2N19
Foam Frame ASSY (6)
Grade No. Part no.
6.1 IFP16051000
6.2 SL70461800
6.3 CWS134005-101
6.4 IPB-XL0011900
6.5 B10009900
Connect Frame ASSY (7)
Grade No. Part no.
7.1 IFP16040700
7.2 FE97085100
Upper Connection Frame ASSY (8)
Grade No. Part no.
8.1 IFP16040800
8.2 B10009900
Long Swing Frame ASSY (10)
Grade No. Part no.
10.1 IFP16041000
10.2 GB2766205-2ZC3
10.3 GB77M8*6DHS2
28
Description
Handle Frame
Grip STΦ31*Φ24*130
Aluminum Grip Cap
Aluminum Grip Ring
Socket Set Screw 10-32UNF*3.2
Description
FOAM Frame
Pin ASSY
Bushing Φ45*Φ38*Φ32*25
Plug 60
Plug Φ50.8
Description
Connect Frame
Bushing Φ38*Φ25*7.5
Description
Upper Connection
Plug Φ50.8
Description
Long Swing Frame
Bearing 6205
Socket Set Screw M8*6
Prone Leg Curl
Qty.
1
2
2
2
8
Qty.
1
1
2
1
1
Qty.
1
4
Qty.
1
1
Qty.
1
2
1
