Taurus Prone Leg Curl IFP Assembly And Operating Instructions Manual page 27

32 GB5780M10*80DHS20
33 GB5780M10*100DHS20
34 NM10DHS2
35 HVSE1113
36 NBS4DHS
37 NBS6DHS
38 NBS8DHS
Main Frame ASSY (1)
Grade No. Part no.
1.1 IFP16040100
1.2 GB17880.5M6*16.5DS17
1.3 IFP12013300
1.4 GB818M6*20DHS2
1.5 83004700
Cushion Frame ASSY (2)
Grade No. Part no.
2.1 IFP16040200
2.2 GB17880.5M6*16.5DS17
2.3 KPSFID2800
2.4 IFP12013300
2.5 GB818M6*20DHS2
Swing Frame ASSY (4)
Grade No. Part no.
4.1 IFP16040400
4.2 IF93051500
4.3 B10009900
4.4 GB2766205-2ZC3
4.5 GB819M6*10DS2
Hex Head Bolt M10*80
Hex Head Bolt M10*100
Nylon Lock Nut M10
Spacer Φ31.8*Φ25.4*35
Key S=8
Key S=6
Key S=4
Description
Main Frame
Rivet Nut M6
Bottom Plug
U-nut M6*20
Bumper 45*25*10
Description
Cushion Frame
Rivet Nut M6
Plug 50.8*76.2
Bottom Plug
U-nut M6*20
Description
Swing Frame
Wear Plate
Plug Φ50.8
Bearing 6205
Philips Countersunk ScrewM6*10
2
6
12
1
1
1
1
Qty.
1
1
1
1
1
Qty.
1
2
1
2
2
Qty.
1
1
1
2
4
27
