Parts List - Taurus Prone Leg Curl IFP Assembly And Operating Instructions Manual

7.2

Parts List

Overall
Item no. Part no.
1 IFP160401ASSY
2 IFP160402ASSY
3 IFP16040300
4 IFP160404ASSY
5 IFP160405ASSY
6 IFP160510ASSY
7 IFP160407ASSY
8 IFP160408ASSY
9 IFP16040900
10 IFP160410ASSY
11 IFP160411ASSY
12 IFP160412ASSY
13 IF93012600
14 IF93215100V2
15 IF81241100V6
16 IFP16041400
17 IN-D21202000
18 FE97211900
19 FE97212000
20 IT80053700
21 IF93062200
22 HF985A1500
23 IT80011800DS
24 CWP311004-101
25 GB894.125FH12
26 GB9510DHS2
27 GB9310DHS12
28 CNLM10*25DHS20
29 GB70M10*25DHS20
30 GB5781M10*30DHS20
31 GB5780M10*75DHS20
26
Description
Main Frame ASSY
Cushion Frame ASSY
Bottom Connection Frame
Swing Frame ASSY
Handle Frame ASSY
FOAM Frame ASSY
Connect Frame ASSY
Upper Connection Frame ASSY
Long Shaft
Long Swing Frame ASSY
Front Base Frame ASSY
Weight Horn ASSY
Shaft
Chest Pad
FOAM Assembly
Seat Pad
End Cap Φ38*Φ10.5*8
Cap Φ60
Circle Ring Φ62.5*5
Big CollarΦ90*Φ51.5*6
Big Flat Washer Φ62*Φ10.5*3
BumperΦ76*Φ42*25
Adjustable Ring
Big Flat Washer Φ60*Φ26*3
Retaining Snap Ring
Flat Washer Φ11*Φ20*2
Spring Washer Φ10
Flat Head Cap Screw M10*25
Socket Head Cap Screw M10*25
Hex Head Bolt M10*30
Hex Head Bolt M10*75
Prone Leg Curl
Qty.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
3
2
2
2
1
2
2
1
36
6
4
3
4
11
