2.3

Assembly

Before assembly, take a close look at the individual assembly steps shown and carry out the assembly
in the order given.
NOTICE
L
+ First loosely screw all parts together and check that they fit properly. Tighten the screws
using the tool only when you are instructed to do so.
+ If you have difficulty recognising the graphics, we recommend that you open and/or
download the PDF instructions stored in the webshop on your end device (e.g. smartphone,
tablet or PC). There you have the option of zooming in closer. Please note that the Adobe
Acrobat Reader programme must be installed on your end device in order to open the file.
+ For better readability, the addition "ASSY" to the name of some assembly components has
been omitted in the assembly instructions. The abbreviation refers to components that
consist of more than one component but have been pre-assembled by factory. Please note
that the abbreviation is used in the parts lists and exploded drawings as it may be relevant
for ordering spare parts.
Required Tools
Ratchet Wrench and Socket
Adjustable Wrench
Rubber Mallet
Hex Key Wrench Set
Phillips Screwdriver
