- Page 1 Assembly and Operating Instructions max. 180 kg ~ 180 Min. 236 kg L 116 | W 154 | H 220 SESS7133.01.01 SKU: SESS7133 Taurus Dual Pro Assisted Chin & Dip...
- Page 2 Chin & Dip...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing... - Page 4 Chin & Dip...
- Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 7: General Information
GENERAL INFORMATION Technical Data Weight and Dimensions Packaging dimensions (L x W x H) and article weight (gross, incl. packaging): Box 1: 163 cm x 91 cm x 19.5 cm 25 kg / 55 lbs Box 2: 152 cm x 89 cm x 28.5 cm 35 kg / 77 lbs Box 3: 170 cm x 103.5 cm x 36 cm... -
Page 8: Personal Safety
Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 9: Set-Up Place
Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. CAUTION ⚠ Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 10: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. - Page 11 Number Name Quantity Frame Pulley set ( 114) Φ Pulley set ( Φ Pulley baffle Left shield + rear 005 + 008 + middle trim + right shield Left shield + front 005 + 009 + middle trim + right shield Side shield Tray Connecting strip...
- Page 12 10lb top weight Cable set 33-2 High foot frame Short foot frame 36-2 Left parallel bars frame Right parallel bars 37-2 frame Horizontal bar bracket Left bracket Right bracket 35-2 Joint frame Leg pad Chin & Dip...
- Page 13 Glide frame 34-2 Main frame Sliding guide rod...
-
Page 14: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. Step 1: Assembly of the Frame and Foot Frames Fix the joint frame (35-2) to the frame (001) with four screws (027), four spring washers (033-1) - Page 16 Step 2: Assembly of the Main Frame, Pulleys and Cable Routing NOTICE The majority of the pulleys are pre-assembled when delivered. These pulleys (65) need to be disassembled in order to perform the cable routing. The two pulleys (012 and 013) for the frame are not pre-assembled. Pass the cable (46) over the pulley (013) [point A] and fix the pulley (013) to the upper side of the frame (001) and pulley baffle (004) with the pre-assembled screw (026), two flat washers (031) and one nut (034-1).
- Page 18 Step 3: Assembly of the Parallel Bars and Brackets Fix the left and right parallel bars frame (36-2 & 37-2) to the main frame (34-2) with a total of four screws (90), four spring washers (99) and four plain washers (102) as well as one screw (89), two plain washer (101) and one lock nut (103).
- Page 20 Step 4: Assembly of the Horizontal Bar Bracket Fix the horizontal bar bracket (42) to the main frame (34-2) with two screws (91), four plain washers (102) and two lock nuts (104) as well as one screw (90), one spring washer (99) and one plain washer (102).
- Page 22 Step 5: Assembly of the Sliding Guide Rods and Glide Frame Slide the glide frame (38) along with four cushion collars (118) over the sliding guide rods (54). Attach the sliding guide rods (54) to the main frame (34-2) with a total of four rubber bushings (75), four rod fixing rings (51), eight screws (84) and eight spring washers (96).
- Page 24 Step 6: Assembly of Leg Pad Frame and Pad Fix the leg pad (105) to the leg pad frame (39) with four screws (106), four spring washers (97) and four plain washers (100). Name Specification Qty. Leg pad frame Spring washer Φ16*Φ8.4*1.6 Plain washer Leg pad...
- Page 26 Step 7: Assembly of the Weight Stack NOTICE The guide rods are pre-assembled to the frame. Disassemble the upper part of the guide rods (002) by removing the screws (021), the guide rod fixing sleeves (003), the split washers (028) and the bumpers (014). Carefully slide each of the 20lb weight plates (61), followed by the 10 lb weight plates (60), over the guide rods (002) one by one.
- Page 28 Step 8: Assembly of the Shields and Trims NOTICE The left and right shields are pre-assembled with a front or rear middle trim. Make sure to align the shields in the respective direction (front/rear). Fix the left and right shields (005 & 006) with the rear and front middle trim (008 & 009) to the frame (001) with four screws (022).
-
Page 30: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 31: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 32: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Cables Screw connections Pulleys and cable routing... -
Page 33: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape. -
Page 34: Ordering Spare Parts
The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / multi gym Model Name: Dual Pro Assisted Chin & Dip SKU: SESS7133 Chin & Dip... -
Page 35: Parts List
Parts List Name Specification Qty. Frame Guide rod Guide rod fixing sleeve Pulley baffle Left Shield Right Shield Side Shield Rear middle Trim Front middle Trim Connecting strip Pulley set φ89*25.8 Pulley set φ114*32 Bumper φ38*φ21*10 Floor mat Bumper φ62*φ20*26 Guide rod upper cap Hook stop collar Single Side glue cushion... - Page 36 Flat washer Φ24*Φ13*2.5 033-1 Spring washer 034-1 Nylon nut 035-1 036-1 Stopple Φ10*Φ5.3*1 037-1 Elastic cylindri cal pin φ10*45 33-2 High foot frame 34-2 Main frame 35-2 Joint frame 36-2 Left parallel bars frame 37-2 Right parallel bars frame Glide frame Leg pad frame Left bracket Right bracket...
- Page 37 Circlips for hole Φ40 Circlips for shaft d0=25 Pulley Φ114*25.4 Rubber foot 180*120*16 Handle grip Φ37.5*Φ31*240 Rubber bumper 25*25*4.6 Foot plate rubber sheet 260*105*18 Rubber cushion Φ38*Φ33*15 Handle grip Φ25*150 Elliptical tube stopper PT40*80*3 rubber bushing Φ36*Φ25*21 Rotary knob Φ41*30.5*M10 Aluminum end cover Φ50*15 Handle grip...
- Page 38 Leg pad Hex socket head cap screw M8*35 10lb weight stack plate 4.5KG Aluminum ring Φ42*Φ33*13 Aluminum ring Φ39*Φ30*14.5 Plastic ring Φ37*Φ33*4.5 Aluminum end cover Φ45*Φ6.5*14 Hex socket head cap screw M6*25 hexagon socket set screw with cone point M5*5 Aluminum end cover Φ38*Φ6.5*13 Plastic ring...
-
Page 39: Exploded Drawing
Exploded Drawing... - Page 40 Exploded View Chin & Dip...
-
Page 41: Warranty
WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 42 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
-
Page 43: Contact
CONTACT TECHNICAL SUPPORT TECHNICAL SUPPORT & SERVICE TECHNICAL SUPPORT & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de ��... - Page 44 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store www.sport-tiedje.co.uk for home fitness equipment with currently over www.sport-tiedje.de/blog 70 stores and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 www.facebook.com/SportTiedje web shops in the respective national language or have their desired equpiment assembled on...
- Page 45 Notes...
- Page 46 Notes Chin & Dip...
- Page 48 Dual Pro Assisted Chin & Dip...
