Testmode: Running the Dump mode
Data/
Step Ready Error
6 The printer is now in Dumpmode and the printer scans the
communication ports. The printer will print any characters it
received on the communication ports to a label when exiting
dump mode.
7 Tap the button once to exit Dumpmode. If you tap the button
within two seconds of entering dump mode, no labels are
printed.
8 1

Extended Testmode

The extended testmode can be used to run additional tests. This
includes the option to print test labels, running a testfeed in slow
mode, entering dump mode and resetting to factory defaults.
The extended Testmode is entered by raising the printhead, and
switching power on while keeping the Print button pressed.
Extended Testmode will run a sequence which can be controlled
via the Print button, and raising or lowering the printhead. The
sequence of steps in the Extended Testmode follows in the table:
Extended Testmode: Activating
Data/
Step Ready Error RtW Button Comment
1
2 flash flash
EasyCoder PD41 Printer User's Guide
Chapter 5 — Setting up the Printer
RtW Button Comment
1
1 Make sure the printhead is
lifted. Press and hold the
Print button and switch the
printer On. Extended
Testmode is activated after
10 seconds.
flash All 3 LEDs flash rapidly four
times. Extended Testmode is
activated. Release button to
continue.
The printer will start as on
rebooted status. When
operational, Data/Ready
and RtW will be lit.
