Peel-Off (Self-Strip) Operation

This section describes the case when self-adhesive labels are
separated from the liner immediately after printing. The same
procedure is followed when installing media for Batch Takeup,
with the difference that both label and liner is rewound, and the
label-taken sensor is not used. These modes of operation require
an optional internal rewinder unit, see Appendix F, "Options."
This is also known as self-strip operation. The label-taken sensor
can hold the printing of the next label in a batch until the present
label has been removed. Only self-adhesive labels with liner can
be used in peel-off operation.

Peel-Off

1
Remove the front cover.
EasyCoder PD41 Printer User's Guide
Chapter 2 — Operating the Printer
2
Open the cover, mount the media roll,
and route the media through the
media feed rods.
17
