HP Compaq t1010 Supplementary Manual page 195

PC Card Adapters for Token Ring Networks
Figure 30–1: RACORE - Token Ring Adapter Settings Dialog
Box
Table 30–1 discusses the dialog box.
Table 30–1:
Function
User Defined MAC Address
Token Ring Speed
30–2
RACORE - Token Ring Adapter Settings
Description
Use this text field to enter the MAC address
of the token ring PC card. The default is
000000000000.
Use this group box to select the speed of
your token ring network. The default is 16
Megabits/Second
4 Megabits/Second
Click on this radio button if your network is
set to a passing speed of 4 megabits.
16 Megabits/Second
Click on this radio button if your network is
set to a passing speed of 16 megabits.
Administrators Guide
