Aironet Wireless Lan Adapter Setup; Using The Aironet Dialog Box - HP Compaq t1010 Supplementary Manual

Aironet Wireless LAN Adapter
✎
This section applies to Compaq T1010 terminals.
The Aironet dialog box (Figure 24–1) allows you to configure
the Aironet wireless LAN adapter solely by menu selections. To
open this dialog box:
1. Press
2. Click on the Devices tab.
3. Double-click on the Aironet icon in the icon container on the
Devices properties sheet.
Figure 24–1: Aironet Wireless LAN Adapter Setup Dialog Box

Using the Aironet Dialog Box

To configure the wireless LAN adapter, select a property from the
Property list and select the desired value from the Value
drop-down menu. Repeat the process for each listed property.
Administrators Guide
to open the Terminal Properties dialog box.
F2
24
Setup
24–1
