Application Diagram

The following figure shows an example of types of devices that can be connected to some of the ports on the
IPL EXP expansion interfaces and IPCP Pro xi Series control processors.
Figure 2. An IPL EXP S5 and IPCP Pro 360Q xi Application

Device Control

The system, including the IPCP and the IPL EXP, must be configured in one of the following ways before it will
send commands to a projector, display, or other device:
• An IR, RS-232, or Ethernet driver file can be downloaded from the Extron website
(www.extron.com/download/index.aspx). The driver is saved to a folder and commands from the driver
are incorporated into the GC configuration file for the control processor and any expansion interfaces, button
panels, and touchpanels that work with it. The configuration file is built and uploaded to the IPCP via GC.
• If a driver is not already available, RS-232 or Ethernet command strings can be entered directly from a host
computer using Global Configurator. These can then be incorporated into controls within the GC project.
See the Global Configurator Help File (which comes with the software) or the help files for Global Scripter or
the ControlScript Deployment Utility for details on setting up the IPL EXP and the IPCP and for downloading,
programming, or configuring device control commands.
RS-232
Monitor
HDMI
DXP 42 HD 4K Plus
POWER
INPUTS
12V
1 2 3 4
1.5A MAX
HDMI HDMI HDMI HDMI
HDMI
HDMI
Laptop Laptop
IPL EXP S5
COM
2 4
1 3
Tx Rx G Tx Rx G Tx Rx G Tx Rx G
RESET
RS-232
Monitor
AV LAN
HDMI
Ethernet
OUTPUTS AUDIO OUTPUTS REMOTE
1 2 3 4
L R L R RS-232
HDMI/CEC HDMI/CEC Tx Rx G
LAN
IPL EXP S5
LAN/PoE
5
Tx Rx G
Ethernet
Ethernet
IPCP Pro 360Q xi
100-240V ~ 1.5A MAX
COM 1 COM 2 COM 3 DIGITAL I/O
Tx Rx G RTSCTS Tx Rx G Tx Rx G 1 2 3 4 G
IR/SERIAL RELAYS eBUS
1 2 1 2 C 3 4 C +V +S -S G
S G S G PWR OUT = 6W
50-60 Hz
IPL EXP I/O Series • Introduction
IPCP PRO 360Q xi
00-05-A6-XX-XX-XX 00-05-A6-XX-XX-XX
MAC: 00-05-A6-XX-XX-XX MAC: 00-05-A6-XX-XX-XX
IPCP AV LAN IPCP LAN
S/N: ####### E###### S/N: ####### E######
AV LAN
LAN
1 2 3
PoE+ OUT PoE+ OUT
Ethernet
Doc
Laptop PC DVD VCR Tuner
Cam 1 2 3
Display Volume
Tuner
On
Channel Presets
1 2 3
Off
4 5 6
Mute Mute
7 8 9
Room
Last
Control
0 More
Presets
Screen Enter
Lighting System Audio
Help December 15, 2013 - 7:58 AM
Off Control
TLP Pro 1220MG
4
