Unidirectional Control and Communication Connections

IR/Serial output ports
An IPL EXP 200 can use infrared signals or unidirectional RS-232 serial signals to control various devices (up to
four per port for IR) via these ports. Set output signal type (IR or serial) during configuration. The following figure
shows wiring examples.
To a Projector,
Panel Display, or the IR or RS-232
Output
Wired IR Remote or
Ground
RS-232 Port of a
Source Device
Figure 9.
Serial control — Connect the IR/S port to the serial control receive (Rx) and ground pins of the device to be
controlled. These ports have the same
IR control — Connect the IR/S port directly to the wired IR port of another device. Alternatively, insert the wires
from up to four IR Emitters into an IR port and place the heads of the emitters over or next to the IR signal pickup
windows of the devices. For wiring, see the following diagrams or the IR Emitter Installation Guide (available on
www.extron.com).
NOTE: Each emitter must be within 100 feet (30.4 meters) of the EXP for best IR control results.
Installing One Single Emitter
Ground (−)
IR Signal (+)
One Single IR Emitter
Installing Two Single Emitters
When installing only single emitters, tie them in series as shown below.
Ground (−)
(−)
(+)
IR Signal (+) (−)
(+)
Two Single IR Emitters
IPL EXP 200
Rear Panel
1 2 3
Tx Rx G Tx Rx G
S G S G S G S G
COM 1 COM M 1 1
COM 2 COM 2 2 2 IR/S R R R RELAYS R R E E E L L
Tx Rx G Tx Rx G 5 S G 6 7 1 2 C 1 2 C
S G S G S G S G
IR/SERIAL
or
Unidirectional
IR
Wiring the IR/Serial Port
serial protocol
Installing One Dual Emitter
Ground (−)
IR Signal (+)
IR/Serial Ports
Output options:
• IR (30 kHz to 300 kHz,
with or without carrier signals)
• Unidirectional RS-232
4
AYS
8
(-)
(+)
(-)
(-)
Ground
G
IR Output Signal
S
(+) (+)
Two Single IR Emitters
options (see page 17) as the COM ports.
Dual IR Emitter
IPL EXP I/O Series • Hardware Features and Installation
To the IR Receiver of a
Projector, Display, or
Source Device
