Table 2-4: ECAT-DI16DO16-M-NN Pin Assignment

Pin Signal
2 E24V External power supply
4 IO_PWR I/O power supply
Mechanical input /
6 DICOM
general input
8 IO_GND I/O ground
10 DI2 Digital input
12 DI4 Digital input
14 DI6 Digital input
16 DI8 Digital input
18 DI10 Digital input
20 DI12 Digital input
22 DI14 Digital input
24 DI16 Digital input
26 DO2 Digital output
28 DO4 Digital output
30 DO6 Digital output
32 DO8 Digital output
34 DO10 Digital output
36 DO12 Digital output
38 DO14 Digital output
40 DO16 Digital output
20
Description Pin Signal
1 E24V External power supply
3 IO_PWR I/O power supply
Mechanical input /
5 DICOM
general input
7 EGND External power ground
9 DI1 Digital input
11 DI3 Digital input
13 DI5 Digital input
15 DI7 Digital input
17 DI9 Digital input
19 DI11 Digital input
21 DI13 Digital input
23 DI15 Digital input
25 DO1 Digital output
27 DO3 Digital output
29 DO5 Digital output
31 DO7 Digital output
33 DO9 Digital output
35 DO11 Digital output
37 DO13 Digital output
39 DO15 Digital output
Description
