1.5 Accessories

Available terminal bases include:
ECAT-TB32-M-DIN: Terminal board exclusive for ECAT IO

M type.
ECAT-TB32-U-DIN: Terminal board exclusive for ECAT IO

DB type.
1.5.1

Features

32-channel ECAT IO Terminal Base

Field I/O wiring connection for ECAT I/O modules

Spring terminal for easy field wiring

Power and ground included for each signal channel

Interlocking design for rugged installation

Power LED indicator

DIN rail mounting

Series
ECAT-TB32-U
For DB Series ECAT-TB32
ECAT-TB64
For M Series ECAT-TB32-M
Model Specifications
(1): 32 channels direct
connected terminal base
(2): One DB slot
(1): 32 channels direct
connected terminal base
(2): One DB slot
(1): 64 channels direct
connected terminal base
(2): Two DB slots
32 channels direct
connected terminal base
for ECAT IO M-series
module
ECAT IO Series
Supports
All ECAT IO DB-
series modules
All ECAT IO M-
series modules
