2.3 Connectors and Indicators

2x RJ45
EtherCAT Ports
32x IO LED
Indicators
40-Pin Signal Connector

Figure 2-5: Connector and Indicator Layout

ECAT IO Series
2x Slave ID
Address Switches
4x System LED
Indicators
13
