h. Fix cables by using self-adhesive cable ties.
All cables must be fixed to the plate to avoid any kind of squeezing during movement
i. Please drive the Baselifts to their lowest position.
7. Mount the kitchen cabinets and the Desk Panel in the kitchen tabletop
a. Mount the kitchen cabinets.
b. Mount the Desk Panel in the hole in the tabletop.
c. (If wireless) Plug the cable from the desk panel into the RF Transmitter. Place and mount the RFT and desk panel,
so the user always has the height adjustable application in sight when adjusting. Remember to place the RFT an
accessible place as it contains batteries that can be replaced
d. Mount the tabletop.
e. Test to see if the kitchen functions.
8. Mount the base cover
a. The base cover must be mounted prior to use to avoid any collision situations or squeezing.
b. Pin the clips on the brackets.
c. Remove the protective film from the clips and mount the bottom base. For better fixing, you can choose to mount
the clips with screws. Ensure that the base cover is mounted to sustain a constant load of the system.
d. It is important to keep a bit of space between the top base and the bottom base to avoid scratches when the kitchen is
driven up and down. The space can be created by adding felt pads on the back of the top base.
e. To calculate where to fix the top base you need to take two measurements. First, you measure from the edge to the top
base. Then add half the width of the base.
9. Make sure that no tools or other equipment has been left under the base
10. Test the function of the kitchen (full stroke in and out) to ensure everything works correctly
You can find the mounting instruction video via
this link
Page 15 of 32
