  • Page 1 Linear Actuators and Electronics User Manual LINAK.COM Page 1 of 192...

  • Page 2: Table Of Contents

    LA20 Inline . . . . . . . . . . . . . . . . . . .
  • Page 3 5. Information on specific control boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101 Generel information .
  • Page 4 8. Information on specific accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170 Generel information .

  • Page 5: Preface

    This User Manual does not address the end user . It is intended as a source of information for the equipment or system manufacturer only, and it will tell you how to install, use and maintain your LINAK electronics . The manufacturer of the end product has the responsibility to provide a User Manual where relevant safety information from this manual is passed on to the end user .

  • Page 6: Valid For

    Valid for This User Manual is valid for the following products: Actuators: LA20, LA23 MEDLINE ® CARELINE ® , LA23 IC, LA27, LA28, LA28 Compact, LA30, LA31, LA32, LA34, LA40 HOMELINE , LA40 MEDLINE CARELINE , LA43, LA43 IC, LA44, LA44 IC ®...

  • Page 7: Important Information

    Output ratings: Nominal values: On LINAK control boxes, battery boxes and power supply marking plates, the nominal output voltage at a certain load for a certain product may be stated . Depending on product and load, this value may vary significantly due to construction .
  • Page 8 IEC 60601-1-2 requirements . Emission: LINAK Actuator Systems are CISPR 11, Group 1, Class B products, comply with IEC 61000-3-2, Class A and IEC 61000-3-3 unless stated otherwise in the relevant section of this document .
  • Page 9 Warning LINAK battery packs contain toxic substances . If the internal battery fluid leaks out and gets onto skin or clothing, make sure it is washed off with clean water . Moreover, if the fluid gets into the eyes, rinse them immediately with clean water and seek medical assistance .
  • Page 10 Therefore, it is clear that LINAK cannot take responsibility for any failures that occur due to Li-Ion battery inherent failures . If any of the Li-Ion batteries built into LINAK products is found to be defective under warranty, LINAK will provide a new product to the OEM . LINAK explicitly disclaims all other remedies .

  • Page 11: Generel Assembly Instructions

    • Note: - When changing the cables on a LINAK actuator system, it is important that this is done carefully in order to protect the plugs and pins . Please ensure that the plug is in the right location and properly inserted before the cable lid is mounted .

  • Page 12: Declaration Of Incorporation Of Partly Completed Machinery

    CA30, CA40, CB6, CB6S, CB6OBMe, CB6P2, CB8, CB9, CB12, CB14, CB16, CB20, CBJ, CBJ Care, CBJ Home, CO41, CO61, CO65, CO71, PJ2 Linear Actuators LA12, LA20, LA22, LA23, LA27, LA28, LA29, LA30, LA31 MEDLINE CARELINE, LA32, LA34, LA40 MEDLINE CARELINE, LA43, LA43IC, LA44, LA44IC Lifting Columns...

  • Page 13: System Description

    • Adjustment of beds • Patient hoists within the care and hospital sector • Adjustment of dentist chairs/gynaecological chairs • Etc . The principles of a LINAK system are as follows: LINAK control box LINAK actuators or lifting columns LINAK hand control Attention should be paid to the following: •...

  • Page 14: Electrostatic Discharge (Esd)

    • ESDS devices must under no circumstances, during transport, storage, handling, production or mounting in an application, be exposed to harmfull ESD . • LINAK can only guarantee the lifetime of ESDS devices if they are handled in the same way from production at LINAK A/S until they are mounted in the manufacturer’s application .

  • Page 15: General Warranty Periods

    These are general warranty periods . Some segments may have special warranty agreements depending on application types . Ex . TECHLINE solar applications . And some customers have Quality agreements with LINAK . These are to be handled accordantly .

  • Page 16: Ip Protection Degree

    Cleaning with a steam cleaner is not permitted . IPX6 Washable The LINAK understanding of the word ‘washable’ is that the products conform to the following and none other: Reference: The standard IEC 60601-2-52, cl . 201 .11 .6 .6 .101 .

  • Page 17: Maintenance

    • LINAK products must be IPX6 Washable and IPX6 Washable DURA when cleaning in wash tunnels • O-rings: When individual parts are replaced in a LINAK IPX6, IPX6 Washable or IPX6 Washable DURA system, the O-rings must be replaced at the same time on all parts On control boxes with a replaceable mains fuse, the O-ring in the fuse cover must be replaced every time the cover has been removed The O-rings must be greased in water-free Vaseline when replacing them .

  • Page 18: Insulation Class

    Insulation class LINAK control boxes are available in insulation class 1 and insulation class 2 . ® Key to symbols The following symbols are used on the LINAK product labels: IEC 60417-5172: Recycle Class II equipment Product with a thermofuse...

  • Page 19: Etl Marking

    Cert . to CSA Std . C22 .2 No . 60601-1 Mounting Actuator: Do not use any other screws for the mounting brackets than those recommended by LINAK ® . If longer screws are used, they will come into contact with the inner parts of the actuator .

  • Page 20: Drawings

    Drawings Figure 1 Figure 2 Ventilation of external batteries, BA18 Check at regular intervals that the ventilation Ventilation stub stub is undamaged and intact . The construction of the ventilation stub permits battery gasses to get out, but it does not permit penetration of water . Figure 4 Figure 3 Figure 6...
  • Page 21 Drawings Figure 6 4) LA12 5) LA30, LA30S, LA32 and LA34 with potentiometer Colour codes: Black Brown Orange Yellow Grey Blue Purple Green White 6) LA30, LA30S and LA32 with optical encoder Page 21 of 192...
  • Page 22 Figure 6 7A-B) LA28/28S/32 with CS28/28S/32 - PC-board version A and B Version A Version B LINAK hand control HB is connected LINAK hand control HB is connected with a telephone plug with a DIN plug 7C) LA28/28S/32 with CS28/28S/32 - PC-board version C...
  • Page 23 Drawings Figure 6 9) LSD 10) LA31, LA34 with electronic pulse coder (reed-switch) 11) LA31 TECHLINE Reed Switch Motor Black Blue + Brown - = Runs outwards Blue - Brown + = Runs inwards 12) LA12 PLC O P E N C O L L E C T O R P N P O R S W I T C H .
  • Page 24 Drawings Figure 6 13) Pin-connection for Mini-fit plug (valid for 13 and 14) Mini-Fit Connector Pin 1 Pin 2 Pin 3 Pin 4 Pin 5 Pin 6 Connector front view PCBA Header top view 0273011 with O-ring WITHOUT FEEDBACK LA27 Mini-fit plug cable (LA27 standard; Valid for LA27 article numbers = 27xxxxxxxxxxxx0) CH1-4 MiniFit: When a channel is operated UP 3: Brown: +...
  • Page 25 Drawings Figure 7 Figure 8 Figure 10 Figure 9 Page 25 of 192...

  • Page 26: Connecting The System

    Connect the different actuators to the different channels on the control box . Each channel is marked with a number (e .g . “1”, “2”, “3”…… .) . Check that all plugs are well connected and firmly pushed into the connector . Due to the fact that LINAK control boxes are designed for a high IP ®...

  • Page 27: Batteries

    • Allow the battery to settle to room temperature before use . • Lithium ion batteries are not intended for use in outdoor applications and indoor pool environments . • If the battery is completely discharged, then recharge the battery before storage . • Always use correct LINAK ® charger .
  • Page 28 . Hereafter, the screws in the cover are to be fastened with approx . 1 Nm . If the seal is damaged, it must be replaced by a new silicone string (LINAK article no . 0008004 for a roll of 100 meters) .

  • Page 29: 2. Information On Start-Up, Deinstallation And Operation

    • The actuator/lifting column system may only be used in an environment corresponding to the IP rating of the system . LINAK products are marked with the actual IP rating on the label . • If any individual parts are suspected to be damaged, do not install the parts, but return them for inspection/service .

  • Page 30: Troubleshooting Actuators/Lifting Columns

    Troubleshooting Actuators/Lifting columns Symptom Possible cause Action - The actuator is not connnected to the control box - Connect the actuator to the control box No motor sound or movement of piston rod - Blown fuse in the control box - Fuse must be changed - Cable damaged - Send actuator for repair...

  • Page 31: Information On Specific Actuators

    • Ensure that the duty cycles and the usage temperatures for LA20 actuators are respected • The LA20 is not suitable for use in outdoor applications where it can be exposed to sun and rain . If outdoor use cannot be avoided, it is very important that the LA20 is mounted in a position where it is well shielded .

  • Page 32: La22

    Cable mounting A: To mount a cable B: To remove/change a cable Step 1: Step 2: Step 1: Step 2: Place the cable in the actuator Press the cable lock down into place Place a screwdriver in the hole in Push to remove the cable lock the back ficture of the actuator an remove/change the cable...
  • Page 33 Warnings • Do not sideload the actuator . • Only use the actuator within specified working limits . • When mounting the LA23 in the application ensure that the bolts can withstand the wear and that they are secured safely . •...

  • Page 34: La23 Medline ® Careline ® Techline

    4. LA23 (MEDLINE CARELINE TECHLINE ® ® ® The LA23 is a small and strong push/pull actuator (up to 2500 N) . The LA23 can be used in various applications where size is important . Some of the benefits the LA23 offers you are: •...
  • Page 35 Recommendations • Do not place load on the actuator housing and do prevent impact or blows, or any other form of stress to the housing . • Ensure that the cable lock is mounted correct . • Ensure that the duty cycle and the usage temperatures for LA23 actuators is respected •...
  • Page 36 Connection diagrams: Standard electrical end stop - no positioning 23XXXXXX00XXXXX BROWN 6 poles connector BLUE Standard electrical end stop and potential free end stop - no positioning 23XXXXXX01XXXXX BROWN BLUE 6 poles connector Common YELLOW GREEN Dual Hall digital positioning Dual Hall PNP positioning 23XXXXXX02XXXXX 23XXXXXX03XXXXX...
  • Page 37 Hall Potentiometer feedback and potential free end stop 23XXXXXX2XXXXXX BROWN BLUE VCC + WHITE ANALOG VIOLET 10 poles connector GND _ BLACK Common YELLOW GREEN Hall Potentiometer feedback 23XXXXXX1XXXXXX 10 poles connector BROWN BLUE VCC + WHITE ANALOG VIOLET GND _ BLACK Hall PWM position feedback and potential free end stop 23XXXXXX4XXXXXX...
  • Page 38 Hall PWM position feedback 23XXXXXX3XXXXXX BROWN BLUE 10 poles connector VCC + WHITE VIOLET GND _ BLACK Standard Integrated Control 23XXXXXX5XXXXXX Integrated Control with Hall Potentiometer position feedback 23XXXXXX6XXXXXX Integrated Control with Hall PWM position feedback 23XXXXXX7XXXXXX BROWN POWER BLUE BLACK INWARDS INPUT...
  • Page 39 Permanent magnet DC motor, available in 12V or 24V EMC noise from the motor is dealt with in LINAK A/S Control boxes . If using the actuator in another aplication it is up to the customer to be EMC compliant .
  • Page 40 Description The actuator can be equipped with two hall sen- Only use for standard actuators, with LINAK A/S sors A and B and a spindle magnet . In this way you Control Boxes for OpenBus™ . can have pulses from the actuator when it moves .
  • Page 41 Input/Output specifications: Dual Hall positioning PNP (03 in ordering example) The Dual Hall positioning PNP is an option on LA23 . This is especially suitable for wheelchairs or Techline applications as the LINAK control boxes have their own option 02 for that purpose .
  • Page 42 Input/ Output specifications: Hall Potentiometer feedback (1x and 2x in ordering example) . The Hall Potentiometer feedback is a an option on LA23 . This is especially suitable for wheelchairs or Techline applications as the LINAK control boxes are not capable of handling the signal .
  • Page 43 Input/ Output specifications: Hall PWM positioning feedback (3x and 4x in ordering example) The Hall PWM positioning feedback is an option on LA23 . This is especially suitable for wheelchairs or TECHLINE applications as the LINAK control boxes are not capable of handling the signal .

  • Page 44: La23 Ic

    5. LA23 IC (TECHLINE ® The LA23 is a small and strong push/pull actuator (up to 2500N) . LA23 can be used in various applications where size is important . The actuator does have build in electrical limit switches and guided nut . Usage: •...
  • Page 45 Connection diagrams: Standard electrical end stop - no positioning 23XXXXXX00XXXXX BROWN 6 poles connector BLUE Standard electrical end stop and potential free end stop - no positioning 23XXXXXX01XXXXX BROWN BLUE 6 poles connector Common YELLOW GREEN Dual Hall digital positioning Dual Hall PNP positioning 23XXXXXX02XXXXX 23XXXXXX03XXXXX...
  • Page 46 Hall Potentiometer feedback and potential free end stop 23XXXXXX2XXXXXX BROWN BLUE VCC + WHITE ANALOG VIOLET 10 poles connector GND _ BLACK Common YELLOW GREEN Hall Potentiometer feedback 23XXXXXX1XXXXXX BROWN BLUE 10 poles connector VCC + WHITE ANALOG VIOLET GND _ BLACK Hall PWM position feedback and potential free end stop 23XXXXXX4XXXXXX...
  • Page 47 Hall PWM position feedback 23XXXXXX3XXXXXX BROWN BLUE 10 poles connector VCC + WHITE VIOLET GND _ BLACK Standard Integrated Control 23XXXXXX5XXXXXX Integrated Control with Hall Potentiometer position feedback 23XXXXXX6XXXXXX Integrated Control with Hall PWM position feedback 23XXXXXX7XXXXXX BROWN POWER BLUE BLACK INWARDS INPUT...

  • Page 48: La27

    6. LA27 (MEDLINE CARELINE HOMELINE ® ® ® The LA27 actuator is a powerful actuator designed for a variety of medical applications . It is developed for both push and pull applications and has a very robust construction because of the ultrasonic welded plastic housing . Usage: •...
  • Page 49 Application requirements: To avoid damage to the LA27 with QR, it is necessary for certain parameters to be specified in the application . You should therefore be aware of the following facts when supplying an LA27QR to a customer . Constant pressure on the actuator: •...
  • Page 50 Mounting bracket instructions: To avoid damage to the actuator when the actuator is in the “rest” position there should be no load / tension on the actuator . LA27 without cable lock LA27 with cable lock Page 50 of 192...

  • Page 51: La28

    • LINAK control boxes are designed so that they will short-circuit the motor terminals of the actuator(s), when the actuator(s) are not running . This solution gives the actuator(s) a higher self-locking ability . If the actuator(s) are not connected to a LINAK control box, the terminals of the motor must be short-circuited to enable self-locking of the actuator .

  • Page 52: La28 Compact

    Recommendations • *LINAK control boxes are designed so that they will short-circuit the motor terminals of the actuator(s), when the actuator(s) are not running . This solution gives the actuator(s) a higher self-locking ability . If the actuator(s) are not connected to a LINAK control box, the terminals of the motor must be short-circuited to enable selflocking of the actuator .

  • Page 53: La30

    LINAK control boxes are designed so that they will short-circuit the motor terminals (poles) of the actuator(s), when the actuator(s) are not running . This solution gives the actuator(s) a higher self-locking ability . If the actuator(s) are not connected to a LINAK control box the terminals of the motor must be short-circuited to achieve the self-locking ability of the actuator .

  • Page 54: La31

    11. LA31 (MEDLINE CARELINE ® ® The LA31 is a compact, quiet and powerful actuator designed for a variety of applications in the MEDLINE & CARELINE segment, such as hospital beds, couches and nursing ® ® home beds . The standard LA31 actuator features known parts such as piston rod eye with slot, and comes in different variations with e .g .
  • Page 55 Max. angle of movement: Note: To ensure operation the Quick Release must be rotated C (max .) due to tolerance/load variation . Some units may operate before 45 C is reached . To avoid damaging the QR, it should not go above 45 Drawing no.: 031944 Recommendations •...
  • Page 56 • If an LA31 is used in an application where there are repeated dynamic (push/pull) movements in the area 2000 - 4000 N, then it is necessary to contact LINAK A/S in order to make a correct specification of the actuator . Repeated push/pull movements cause extra strain to the actuator and can give safety considerations, the consequence being possible damage to the actuator .

  • Page 57: La32

    • Duty cycle: Max . 10 % or 2 minutes continuous use followed by 18 min . not in use • Ambient temperature: + 5 °C to + 40 °C • For use with LINAK control boxes CB8, CB12, CB14 and CS16 PCB or internal CS32 PCB • Approvals: IEC 60601-1:2005, 3 edition, ANSI / AAMI ES60601-1:2005, 3 edition and CAN / CSA-22 .2 No 60601-1:2008 approved...

  • Page 58: La34

    . • LINAK control boxes are designed so that they will short-circuit the motor terminals (poles) of the actuator(s) when the actuator(s) are not running . This solution gives the actuator(s) a higher self-locking ability . If the actuator(s) are not connected to a LINAK control box the terminals of the motor must be short-circuited to achieve the self-locking ability of the actuator .
  • Page 59 This has no impact on the safety of the actuator and is caused by internal frictions . If the LA34 actuator is used in connection with a non-LINAK power supply the system must be equipped with current trip cut-off .

  • Page 60: La40 Homeline

    • The LA40 is not suitable for use in outdoor applications where it can be exposed to sun and rain . Warning • The installation of spline actuators is recommended by LINAK where possible to avoid the squeezing of body parts . • End of life issue: defective switches - endstop: If the electrical endstop switch for outward operation fails, it may cause a prolonged actuator stroke and in addition the customer application may collapse .

  • Page 61: La40 Medline ® Careline

    • The installation of spline actuators is recommended by LINAK where possible to avoid the squeezing of body parts . • The installation of Manual Lowering (ML) is recommended by LINAK where possible to avoid the squeezing of body parts .
  • Page 62 Instruction concerning the turning of the piston rod eye When mounting and taking into use, it is not permitted to turn the piston rod eye several times . In cases where the eye is not positioned correctly, the eye must be screwed to its bottom position (1) and then maximum half a turn outwards again (2) .
  • Page 63 Mounting of the quick release cable: Open the quick release lid using a flat-head screwdriver . Mount the cable in one of the assigned cable mounting holes . For dual release grips, use both holes . Push and twist in release hole . Place cable collar in groove .

  • Page 64: La43

    • LINAK control boxes are designed so that they will short-circuit the motor terminals (poles) of the actuator(s), when the actuator(s) are not running . This solution gives the actuator(s) a higher self-locking ability . If the actuator(s) are not connected to a LINAK control box, the terminals of the motor must be short-circuited to achieve the self-locking ability of the actuator .
  • Page 65 Manual lowering: The following pictures illustrate the manual lowering procedure . Fig. 1. Manual Lowering In case of a power failure it is possible to mechanically lower a patient placed in a patient hoist . When turning the manual lowering handle clockwise the actuator can be moved fully inwards . Fitting the plug/smart cable lock The following pictures illustrate how to fit the plug connection using the smart cable lock manual lowering procedure .

  • Page 66: La43 Ic

    17. LA43 IC (MEDLINE CARELINE ® ® The LA43 Intelligent Control (IC) enables a simple system consisting of 1 or 2 actuators, a Switch Mode Power Supply and a hand control or a footswitch . The system is for example an advantage when there is no space for a control box . Usage: •...
  • Page 67 Cable connections: SMPS connection, 4-pole minifit plug Second actuator connection, 6-pole minifit plug or blind plug Hand control / FS connection, 10-pole modular jack / 6-wire standard cable . Fig. 1 Fig. 2 Step 1: Step 2: Insert the cables in the sockets . Insert the cables into the cable lock .

  • Page 68: La44

    Self-locking ability. • LINAK control boxes are designed so that they will short-circuit the motor terminals (poles) of the actuator(s), when the actuator(s) are not running . This solution gives the actuator(s) a higher self-locking ability . If the actuator(s) are not connected to a LINAK control box, the terminals of the motor must be short-circuited to achieve the selflocking ability of the actuator .
  • Page 69 Manual lowering: The following pictures illustrate a) The manual lowering procedure and b) How to fit and remove the plug connection using the “Smart cable lock” Fig. 1. Manual Lowering In case of a power failure it is possible to mechanically lower a patient placed in a patient hoist . When turning the manual lowering handle clockwise the actuator can be moved fully inwards .
  • Page 70 Feedback specifications Hall Item Specification Comment Description The actuator can be equipped with Dual Hall that gives a relative positioning feedback signal when the actuator moves . The feedback circuit has to be powered 50 ms before Input voltage 4-15V driving and until the actuator has stopped moving Current Maximum 15mA @10kΩ...

  • Page 71: La44 Ic

    19. LA44 IC (MEDLINE CARELINE ® ® The LA44 Intelligent Control (IC) enables a simple system consisting of 1 or 2 actuators, a Switch Mode Power Supply and a hand control or footswitch . The system is for example an advantage when there is no space for a control box . Usage: •...

  • Page 72: Information On Specific Columns

    . Your nearest LINAK dealer can inform you of the number of pulses per stroke length . Regarding reed-switch connection, see Figure 6.10.
  • Page 73 • Do not loosen any screws on the BL1, this can cause collapse of the column ! • LINAK recommends making regular measurement of Class 1 protective ground conductivity in the application to avoid a disconnected grounding cable . Worn out or defect parts must be replaced .
  • Page 74 BL1 end plate kit without cable through: Top plate dimensions: Bottom plate dimensions: BL1 end plate kit with cable through: Top plate dimensions: Bottom plate dimensions: Motor cable Hand control cable Hand control cable Please notice the thickness of the bottom plate is 12 mm . The thickness of the bottom plate without connections is 10 mm . Page 74 of 192...
  • Page 75 Bottom plate dimensions: Motor cable Drawing no .: 0801263-A BL1 Mounting guidelines: • BL1 is for use in push applications, and can be mounted in both directions (smallest profile down, or up) . Note: The cable outlet can be positioned at the top (smallest profile) . If the option with integrated cable is chosen, the cable outlet can also be positioned at the bottom (biggest profile) .
  • Page 76 • Remember to secure the cable mounted in the top of the column to the application, so that it cannot be pulled out of the column . We recommend to use LINAK Cable: - Lock kit for BL1 with motor cable: 0808040 - Lock kit for BL1 with hand control cable through: 0808046 Use only the screws included in the kit .
  • Page 77 When mounting more than one BL1 you need to consider the fixation: Fixed pivot point Moveable pivot point Example 1 . Fixed pivot point Fixed pivot point Example 2 . The reason why it is important only to fix one column, is that the columns will not move exactly in parallel – even if you have positioning such as hall . If more than one column is fixed it can lead to dangerous situations .

  • Page 78: Bl4

    +5 °C to +40 °C Storage temperature: Max . 50 °C Your nearest LINAK dealer can inform the number of pulses per stroke length . Regarding Reed-switch connection, see Figure 6.10. • There are mounting holes in the endplates and motor housing •...
  • Page 79 BL4 Mounting guidelines: • The BL4 must always be mounted vertically before operation and always vertical with the motor housing uppermost . (Otherwise, the internal end-stop switch system can break due to rotation) . • Both the motor housing and the bottom tube (the one with the largest diameter) must be secured in the application in such a way that no rotation can occur .
  • Page 80 If more than one column is fixed, it can lead to dangerous situations . LINAK mounting bracket part no .: 0673003-A Mounting guidelines for the BL4 bracket, supplied by LINAK, part no . 0673003: Mounting the bracket in the application: •...

  • Page 81: Lc2

    4. LC2 (MEDLINE CARELINE TECHLINE ® ® ® The LC2 column is an update of the LP2 programme . It has an improved “twisting” stability and end-stop switches as standard . The column is designed to be used in a vertical position and only for lifting purposes .
  • Page 82 Remember to secure the cable mounted in the top of the column to the application, so that it cannot be pulled out of the column . We recommend to use LINAK Cable: • Lock kit for minifit cable: 1002W8136-A .
  • Page 83 Cable connections overview Top plate Side entry Variant Drawing no .:1002W9005 Drawing no .:1002W9005 T000 Connections 5: Motor T001 Connections 5: Motor Including protective grounding cable T100 Connections 5: Motor 6: Minifit through 3: Minifit through T200 Connections 5: Motor 6: HB through 3: HB through Page 83 of 192...
  • Page 84 T030 Connections 5: Motor 6: Mains through 1 3: Mains through 1 Female connection top entry, Female connection top entry, male connection side entry male connection side entry T040 Connections 5: Motor 6: Mains through 2 3: Mains through 2 Male connection top entry, Male connection top entry, female connection side entry...
  • Page 85 T201 Connections 5: Motor Including protective grounding cable 6: HB through 3: HB through T031 Connections 5: Motor 6: Mains through 1 3: Mains through 1 Female connection top entry, Female connection top entry, Including protective grounding cable male connection side entry male connection side entry T041 Connections...
  • Page 86 T110 Connections 5: Motor 6: Minifit through (top) 3: Minifit through (side) 7: Minifit through (top) 4: Minifit through (side) T120 Connections 5: Motor 6: HB through 3: HB through 7: Minifit through 4: Minifit through T220 Connections 5: Motor 6: HB through (top) 3: HB through (side) 7: HB through (top)
  • Page 87 T130 Connections 5: Motor 6: Mains through 1 3: Mains through 1 Female connection top entry, Female connection top entry, male connection side entry male connection side entry 7: Minifit through 4: Minifit through T140 Connections 5: Motor 6: Mains through 2 3: Mains through 2 Male connection top entry, Male connection top entry,...
  • Page 88 T240 Connections 5: Motor 6: Mains through 2 3: Mains through 2 Male connection top entry, Male connection top entry, female connection side entry female connection side entry 7: HB through 4: HB through S300 Connections 3: Motor supply S400 Connections 3: Motor supply Page 88 of 192...
  • Page 89 S500 Connections 3: Motor supply S301 Connections 3: Motor supply Including protective grounding cable S401 Connections 3: Motor supply Including protective grounding cable Page 89 of 192...

  • Page 90: Lp2

    S501 Connections Including protective grounding cable 3: Motor supply S310 Connections 3: Motor supply 6: Minifit through 4: Minifit through S320 Connections 3: Motor supply 6: HB through 4: HB through Page 90 of 192...
  • Page 91 S410 Connections 3: Motor supply 6: Minifit through 4: Minifit through S420 Connections 3: Motor supply 6: HB through 4: HB through S510 Connections 3: Motor supply 6: Minifit through 4: Minifit through Page 91 of 192...
  • Page 92 S520 Connections 3: Motor supply 6: HB through 4: HB through S330 Connections 3: Motor supply 6: Mains through 1 4: Mains through 1 Female connection top entry, Female connection top entry, male connection side entry male connection side entry S340 Connections 3: Motor supply...
  • Page 93 S430 Connections 3: Motor supply 6: Mains through 1 4: Mains through 1 Female connection top entry, Female connection top entry, male connection side entry male connection side entry S440 Connections 3: Motor supply 6: Mains through 2 4: Mains through 2 Male connection top entry, Male connection top entry, female connection side entry...
  • Page 94 S540 Connections 3: Motor supply 6: Mains through 2 4: Mains through 2 Male connection top entry, Male connection top entry, female connection side entry female connection side entry Page 94 of 192...
  • Page 95 Mounting of a product on the side of an LC3 It is possible to mount a product on all 4 sides of the LC3 at the same time . However, it requires that the holes for mounting are placed with different distances from the top and/or bottom plate .
  • Page 96 Feedback specifications: Potentiometer Ordering code no.: 0P E1 (power switch) F6 (potentiometer) Potentiometer 0V Not connected M+ (motor/power) Potentiometer output Potentiometer VCC M- (motor/power) Feedback specification VCC max . 15 V Potentiometer total resistance 10 kΩ ± 20% Non-linearity ±2% Hysteresis ±2% Calculation of output vs.
  • Page 97 Input/output specifications: dual Hall positioning Dual Hall digital (F3) with power switch Item Specification Comment Pin1 configuration Pin2 Pin3 Pin4 HALL A Pin5 HALL B Pin6 4-15V Current Maximum 15mA @10 kΩ and 1nF load . See diagram . HALL A/B TState is minimum 5ms in all states Signal pattern during movement: (11,10,00,01) at a minimum mechanical load .
  • Page 98 • Do not loosen any screws on the LC3, this can cause collapse of the column! • LINAK recommends making regular measurement of Class 1 protective ground conductivity in the application to avoid a disconnected grounding cable . If there are worn out or defect parts, the complete LC3 must be replaced .
  • Page 99 . The design allows the LP2 range to be built in a complete motion control system simply by adding a suitable LINAK control box and hand control . Advanced design and high quality construction allows the column to be operated either as single or parallel with up to a maximum of four units and/or with a memory function .

  • Page 100: Lp3

    LP2 . The telescopic column is compatible with LINAK’s control boxes and can run individually; as 2 x LP3 parallel and/or with memory . The LP3 is the perfect choice for height adjustment on dental, gynaecologist, and wheelchairs as well as for operating, office and working benches etc .

  • Page 101: Information On Specific Control Boxes

    Control boxes connected to a battery can reach a voltage of 30 V during charging and no load . For all control boxes with battery Prior to first use of LINAK batteries, please make sure that they are being charged 24 hours in order to reach proper function and prolong the lifetime of the batteries .

  • Page 102: Ca30/Ca40

    1. CA30/CA40 (MEDLINE CARELINE ® ® The control boxes CA30 and CA40 are developed as part of a new control box platform for the care and rehab industry . The control boxes can be mounted separately on the application by means of unique slide-on brackets, but also on several actuator models using a specially designed actuator bracket .
  • Page 103 Mounting instructions (Example CA30-CA40 with LA40) When mounting the control box onto the actuator (1) Simply slide on the bracket until you hear a clear click (2) Slide on the control box until you hear a click and the box is mounted (3) It is recommended that the CA30/CA40 is mounted in a position that allows water to escape .
  • Page 104 • Be aware that the channel configuration has been changed compared to existing analogue control boxes . • To avoid unintended movement like trend or antitrend, LINAK recommends the application manufacturer to instruct the end user to avoid that multiple keys are pressed simultaneously .

  • Page 105: Cb6

    • Check that all plugs are well connected and firm pushed into the connection plug . Due to the fact that LINAK control boxes are designed for a high IP degree, a firm force can be required . • CONNECT the mains and turn on the power! •...

  • Page 106: Cb6 Obme

    3. CB6 OBMe (MEDLINE CARELINE ® ® The CB6OBMe is part of the LINAK OpenBus™ product range - that provides more flexible solutions no matter which actuator concept is preferred . Is a powerful control box with Switch Mode Power...
  • Page 107 • A battery stored at 25 °C has to be recharged every 6 - 7 months . • Prior to first use of LINAK batteries, please make sure that they are charged for 24 hours in order to reach proper function and prolong the lifetime of the batteries .

  • Page 108: Cb6P2

    • A battery stored at 25 °C has to be recharged every 6 - 7 months . • Prior to first use of LINAK batteries, please make sure that they are charged for 24 hours in order to reach proper function and prolong the lifetime of the batteries .

  • Page 109: Cb6S

    Mounting of CB6S – article no . 9271233 Apart from LA27 and LA40, it is not possible to mount CB6S onto LINAK actuators . In such case you need a CB6 mounting bracket which can be welded or likewise to the application .
  • Page 110 • A battery stored at 25 °C has to be recharged every 6 - 7 months . • Prior to first use of LINAK batteries, please make sure that they are charged 24 for hours in order to reach proper function and prolong the lifetime of the batteries .

  • Page 111: Cb7

    6. CB7 (HOMELINE ® Compared to other LINAK control boxes the CB7 is very small and compact in design . The CB7 is designed to slide onto an LA31 actuator for easy fitting e .g . in a recliner application where “mounting”...

  • Page 112: Cb8-T

    ® ® ® The CB8-T is developed for use with LINAK A/S’ actuators and handsets . The control box can operate up to 2 actuators individually . The simple compact design combined with high quality makes the control box ideal for use with beds, chairs, tables and many other applications .
  • Page 113 CB9 is equipped with a green LED for indication of mains power connected . • When the CB9 is connected to mains, the LED is green . • Connected only to battery, the LED is off . The cables are locked in position with a locking mechanism . The locking mechanism is shown here (not in position) CB9 for mounting on application .

  • Page 114: Cb9 Careline ® Basic

    Basic CB9 series is only available as an analogue (Ax) type . Microprocessor: With LINAK software packages the Px types are aimed at applications where parallel drive and/or memory functions are required . Please consult the ordering example for a detailed description of the article number .

  • Page 115: Cb14

    All control boxes with a microprocessor must be initialized before start-up . A description of the initialisation procedure can be obtained from your LINAK dealer . If an actuator is replaced, the microprocessor always has to be initialised before use (actuators with reed/hall) .
  • Page 116 Initialisation will in most cases be possible pressing H0 and H1 or H10 and H11 on a hand control . Initialisation depends upon the software description so please obtain a description of the initialisation procedure from your local LINAK dealer .

  • Page 117: Cb20

    CAN/CSA-22 .2 No 60601-1:2008 approved Please be aware: CB20 is delivered in 3 separate units - CU20 + CP20 + BA20 . The units are not assembled at LINAK A/S . Microprocessor All control boxes with a microprocessor must be initialized before start-up . A description of the initialization procedure can be obtained from your LINAK dealer .

  • Page 118: Co41

    The LINAK control box CO41 offers a consolidated range of unprecedented features – all utilising standardised technology, interfaces and compatibility . The CO41 for LINAK actuators is intended for the control of, for example, hospital bed movement . Equipped with 120W SMPS, excellent and well thought-out cable management as well as multiple easy mounting options, this control box opens up a wide range of application possibilities for the provident hospital and care products manufacturer .
  • Page 119 Mounting bracket (frame flat) Mounting bracket (frame flat) w/M4 nuts - article No. 1015W1001: - article No. 1015W9009: Drawing No .: 1015W4001 Drawing No .: 1015W4009 CO41 - mounted on frame: Very small built-in dimension: Height: min . 80 mm (lid can be removed) Release hook Length: + 20 mm (locking system) Service lid...
  • Page 120 Mounting instructions (Example CO41 with LA40) When mounting the control box onto the actuator (1) Simply slide on the bracket until you hear a clear click (2) Slide on the control box until you hear a click and the box is mounted (3) It is recommended that the CO41 is mounted in a position that allows water to escape .
  • Page 121 Mounting of cables and cable lock: CO41 has a uniquely designed cable lid . The lid also works as an integrated cable lock when closed . 1) Mount cable plugs in control box 2) Close lid until lock snaps into place (see arrows) To allow free access to the cables, the lid has a rest position when completely opened .
  • Page 122 (CO41) . • If there is a risk that the system is overloaded and therefore shuts down thermally, LINAK recommends to use quick release actuators . These will allow functions to be lowered manually in case of a CO41 malfunction due to misuse/abuse .

  • Page 123: Co61

    The LINAK control box CO61 offers a consolidated range of unprecedented features – all utilising standardised technology, interfaces and compatibility . The CO61 for LINAK actuators is intended for the control of, for example, hospital bed movement . Equipped with 200W SMPS, excellent and well thought-out cable management as well as multiple easy mounting options, this control box opens up a wide range of application possibilities for the provident hospital and care products manufacturer .
  • Page 124 Mounting bracket (frame flat) - article No . 1015W1001: Mounting bracket (frame flat) w/M4 nuts - article No . 1015W9009: Drawing No .: 1015W4009 Drawing No .: 1015W4001 CO61 - mounted on frame: Very small built-in dimension: Height: min . 80 mm (lid can be removed) Release hook Length: + 20 mm (locking system) Service lid...
  • Page 125 Mounting instructions (Example CO61 with LA40) When mounting the control box onto the actuator (1) Simply slide on the bracket until you hear a clear click (2) Slide on the control box until you hear a click and the box is mounted (3) It is recommended that the CO61 is mounted in a position that allows water to escape .
  • Page 126 Mounting of cables and cable lock: CO61 has a uniquely designed cable lid . The lid also works as an integrated cable lock when closed . 1) Mount cable plugs in control box 2) Close lid until lock snaps into place (see arrows) To allow free access to the cables, the lid has a rest position when completely opened .
  • Page 127 (CO61) . • If there is a risk that the system is overloaded and therefore shuts down thermally, LINAK recommends to use quick release actuators . These will allow functions to be lowered manually in case of a CO61 malfunction due to misuse/abuse .

  • Page 128: Co65

    19. CO65 (MEDLINE CARELINE ® ® The LINAK control box CO65 offers a consolidated range of unprecedented features – all utilising standardised technology, interfaces and compatibility . Usage: • Operation temperature: +5 °C to +40 °C • Storage temperature: -10 °C to +50 °C •...
  • Page 129 Mounting bracket (frame flat) - article No . 1015W1001: Mounting bracket (frame flat) w/M4 nuts - article No . 1015W9009: Drawing No .: 1015W4009 Drawing No .: 1015W4001 CO65 - mounted on frame: Very small built-in dimension: Height: min . 80 mm (lid can be removed) Release hook Length: + 20 mm (locking system) Service lid...
  • Page 130 Mounting instructions (Example CO65 with LA40) When mounting the control box onto the actuator (1) Simply slide on the bracket until you hear a clear click (2) Slide on the control box until you hear a click and the box is mounted (3) It is recommended that the CO65 is mounted in a position that allows water to escape .
  • Page 131 Mounting of cables and cable lock: CO65 has a uniquely designed cable lid . The lid also works as an integrated cable lock when closed . 1) Mount cable plugs in control box 2) Close lid until lock snaps into place (see arrows) To allow free access to the cables, the lid has a rest position when completely opened .
  • Page 132 • To avoid unintended activation of actuators if hand control cables short-circuit, LINAK recommends to use an OpenBus system (CO65) . • If there is a risk that the system is overloaded and therefore shuts down thermally, LINAK recommends to use quick release actuators .

  • Page 133: Co71

    The LINAK control box CO71 offers a consolidated range of unprecedented features – all utilising standardised technology, interfaces and compatibility . The CO71 for LINAK actuators is intended for the control of, for example, hospital bed movement . Equipped with 350W SMPS, excellent and well thought-out cable management as well as multiple easy mounting options, this control box opens up a wide range of application possibilities for the provident hospital and care products manufacturer .
  • Page 134 Mounting bracket (frame flat) - article No . 1015W1001: Mounting bracket (frame flat) w/M4 nuts - article No . 1015W9009: Drawing No .: 1015W4009 Drawing No .: 1015W4001 CO71 - mounted on frame: Very small built-in dimension: Height: min . 80 mm (lid can be removed) Release hook Length: + 20 mm (locking system) Service lid...
  • Page 135 Mounting instructions (Example CO71 with LA40) When mounting the control box onto the actuator (1) Simply slide on the bracket until you hear a clear click (2) Slide on the control box until you hear a click and the box is mounted (3) It is recommended that the CO71 is mounted in a position that allows water to escape .
  • Page 136 Mounting of cables and cable lock: CO71 has a uniquely designed cable lid . The lid also works as an integrated cable lock when closed . 1) Mount cable plugs in control box 2) Close lid until lock snaps into place (see arrows) To allow free access to the cables, the lid has a rest position when completely opened .
  • Page 137 (CO71) . • If there is a risk that the system is overloaded and therefore shuts down thermally, LINAK recommends to use quick release actuators . These will allow functions to be lowered manually in case of a CO71 malfunction due to misuse/abuse .

  • Page 138: Pj2

    ® ® The LINAK Power Junction Box PJ2 offers two extra outputs for the COXX control box series . Standardised technology, interfaces and compatibility like the new COXX control boxes . The PJ2 for LINAK actuators is intended for the control of, for instance, hospital bed and surgery tables movement .
  • Page 139 Mounting bracket (frame flat) - article No . 1015W1001: Mounting bracket (frame flat) w/M4 nuts - article No . 1015W9009: Drawing No .: 1015W4001 Drawing No .: 1015W1009 It is recommended that the PJ2 is mounted in a position that allows water to escape . Recommended torque: 0 .6 Nm +/- 0 .1 The bracket can be mounted to the bed frame or any other application by following one of the following mounting procedures: •...
  • Page 140 Mounting instructions (Example PJ2 with LA40) When mounting the control box onto the actuator (1) Simply slide on the bracket until you hear a clear click (2) Slide on the control box until you hear a click and the box is mounted (3) Cables PJ2 has a uniquely designed cable lid .
  • Page 141 Recommendations • When the system is overloaded, LINAK recommends to use quick release actuators in the application . These will allow functions to be lowered manually in case of a PJ2 malfunction due to misuse/abuse . • If the customer has other basic safeties than “no unintended movement”, he must consider this in his own risk analysis .

  • Page 142: Information On Specific Controls

    ACK1 is with a single keypad, whereas ACK3 is able to work with two keypads at the same time (typically an inside side rail and an outside side rail) . Features and Options: Generel information For LINAK standard ACK’s, the following is applicable: • Straight cables: 1250 mm, 1800 mm or 2500 mm • The standard ACK colour is grey (RAL 7035) •...

  • Page 143: Acl

    3. ACL (MEDLINE CARELINE ® ® The ACL (Attendant Control Lock) box is a one turn button box for various applications where the patient positioning must be carefully controlled by the medical staff . The ACL disconnects all functions on hand control either by means of turn button or turn key . The aim is to minimise the risk of unintended activation of an actuator and hereby minimising the risk of “squeezing”...

  • Page 144: Acom

    • When a defective ACOM is replaced, check that the new ACOM has exactly the same specification and functionality . • Do not submerge the hand control in water . • Unless otherwise specified or agreed with LINAK, the hand control is only intended to be used for LINAK systems . • When changing hand controls for OpenBus systems, the power must be switched off .
  • Page 145 • Before first start-up, be aware not to place any magnetic devices or RFID tags in front of the company logo until the ACT goes into sleep mode to avoid calibration disturbance . • Be aware that magnetic jewellery or magnets in general can activate care mode and lead to unintended use . LINAK recommends to use RFID tags . Warnings: •...
  • Page 146 The recommended screw type is self-tapping BN84229 50 x 12 . A grounding cable (article no .: 1009W7004) will be supplied together with the ACT and must be connected to the OpenBus system and the other end to the bed frame to decouple electrical fields . Ferrite core : If upward cable exit is used, a ferrite core needs to be added as close as possible to the ACT .

  • Page 147: Dph Medical

    The FPP comes with a cable attached . The bottom part of the arm is prepared for mounting inside a bracket - fitting the diameter of the arm . The bracket is not supplied by LINAK but must be designed and made by the customer . It must fit the dimensions shown . A suggestion to a design is illustrated on below pictures as well as the dimensions of the parts for fixation .
  • Page 148 Dimensions lIllustration: Possible bracket design. The FPP must be mounted in such a manner that it is secured against rotation . For this purpose the bracket end of the arm has 4 x drilled holes - one of the 4 holes must be secured via the bracket with a slotted set screw with cone point (pointed screw) . Otherwise it may slide away from the user when operated .

  • Page 149: Fs2

    Floor adaptor Bed adaptor The Foot Switch FS3 is an ergonomically designed modular system, developed for use together with LINAK control boxes and IC actuators with Intelligent Control . The LINAK Foot Switch is designed for easy and improved control of e .g . hospital beds and couches and has been developed in ®...

  • Page 150: Hb20

    You have to remove the nut before mounting the FS3 on the bed and after mounting the FS3 to the bed, the nut is fastened to secure that the FS3 is fixed to the bed frame . Please note that the max . torque on the nut should be 2 .0 Nm (20 kg f . cm) . When mounting the FS3 bed model, it is important to run the cable through the hole of the FS3 in order to lead the cable through (see picture below) .

  • Page 151: Hb30

    15. HB30 (MEDLINE CARELINE ® ® The HB30 hand control is designed for better user experience and ergonomic fit for the hands of caregivers . The compact size ensures one hand operation . The HB30 is especially suitable for patient lifts and other MEDLINE and CARELINE applications like couches, tables and ®...

  • Page 152: Hb40

    • Do not submerge the hand control under water . • Unless otherwise specified or agreed with LINAK, the hand control is only intended to be used on LINAK systems . • Do not sit or lie down on the hand control . It can cause unintended movement of the application .

  • Page 153: Hb50

    Usage: • Compatible with most LINAK control boxes . • Approved according to: EN 60601-1, EN 60335-1 and UL 60601-1 as part of a LINAK actuator system Recommendation • It is not possible to combine HB7x with the binary based CB9 . .PM/PN .

  • Page 154: Hb80

    • Do not submerge the hand control under water . • Unless otherwise specified or agreed by LINAK - the hand control is only intended to be used on LINAK systems . • When changing hand controls for OpenBus™ systems, the power must be switched off .

  • Page 155: Hd80

    . Recommendations • Inform the customer to use only the magnet key supplied by LINAK . We also recommended to make a functional test of the application before putting it into operation . • Clean the hand control regularly to ensure good hygiene standards .

  • Page 156: Hd80 Jumbo

    • Do not submerge the hand control under water . • Unless otherwise specified or agreed by LINAK, the hand control is only intended to be used on LINAK systems . • When changing hand controls for OpenBus™, the power must be switched off .

  • Page 157: Hl80

    • Do not submerge the hand control under water . • Unless otherwise specified or agreed by LINAK, the hand control is only intended to be used on LINAK systems . • When changing hand controls for OpenBus™ systems, the power must be switched off .

  • Page 158: Iro

    ® There are two types of LINAK limit switches, for actuators type LA22, LA30, LA30S , LS, and LSD . The LS type gives a signal in two fixed end positions, but requires a control unit to stop the actuator when the microswitches are activated .

  • Page 159: Information On Specific Jumbo

    Via JUMBO wall charger CHJ2 or via JUMBO control box with integrated charger • Charging state: Maximum 30% when shipped from LINAK • Recharging during storage: Recharge the battery 6 months at the latest after production date stated on the label •...
  • Page 160 . If any of the lithium ion batteries built into LINAK products is found to be defective under warranty, LINAK will provide a new product to the OEM .

  • Page 161: Cbj1/Cbj2

    Warnings Lithium ion batteries differ from the lead acid technology as they have a built-in deep discharge protection . • Loss of power might happen due to the battery deep discharge protection . This will only happen in case of continuous battery use despite warnings .
  • Page 162 Adjustment instructions for the JUMBO application. Tool For the adjustment you must use a trimming screwdriver, which can be purchased from LINAK A/S . It is also possible to use other types of trimming screwdrivers for the adjustment . Ordinary screwdrivers cannot be used, as they will damage the potentiometer slot.

  • Page 163: Cbj-Care

    • It is not possible to use other battery types than BAJ1 or BAJL with the CBJ Care . • Use only original LINAK mains cables to ensure proper connection to internal charger . • The green battery indicator (100% to 50% capacity remaining) will light up during charging even though the battery is not fully charged .
  • Page 164 Recommendations Hot Plugging: Removing or adding any OpenBus™ cables is not allowed when the control box is on power via mains supply or battery! If necessary anyway, follow the below procedure: 1 . Remove mains or battery and wait 5 sec . 2 .
  • Page 165 Charging of battery: When the mains cable is plugged in and a control button is activated the symbol to the left is shown on the display until power down 2 minutes later . The purpose of the symbol is to tell the user that it is not possible to use the lift when it is plugged in to the mains . Short circuit: If there is a short circuit the control box will show the short circuit symbol with a recommendation to check the connections .

  • Page 166: Cbj-Home

    • Always use fully charged batteries for learning mode procedures . • Only an authorised LINAK service centre should change a battery in a CBJ Home . If a CBJ Home is opened and a battery is changed by unauthorised personnel, there may be a risk of malfunction •...

  • Page 167: Cobo

    Power consumption (charging) max . 19 W • Compatibility: LINAK Batteries BAJ1, BAJ2 (24 V, 2 .9 AH) or other 26 - 28 V power sources via customer battery connection . LINAK Lithium Ion battery (BAJL Li-Ion) • Duty cycle: 10 % 2 minutes running and 18 minutes rest •...

  • Page 168: Cobo20

    Warnings • Pay attention to the polarity of the customer battery cable - red is positive voltage . • In order to avoid injury, the emergency stop should be activated in (all) transport situations . • If 24V lead acid customer batteries or fixed power supply is used, the supply source must comply with “Means Of Patient Protection” and “Means Of Operator Protection”...

  • Page 169: Ch01

    8. CH01 (MEDLINE CARELINE ® ® For charging the batteries of CB08-XA and all JUMBO control boxes, directly connected to the control box or via the hand control HB40A . For charging of the batteries in battery box BAJ2 (JUMBO system) and CBJH . 9.

  • Page 170: Information On Specific Accessories

    8. Information on specific accessories If the actuator is to be equipped with accessories, these must be specified when ordering the actuator from LINAK . There are the following possibilities: 1) TR6/TR7 External transformer If the TR6 or TR7 fixed cable connection becomes damaged the transformer must be replaced .
  • Page 171 Mounting instructions: Mounting bracket (frame flat) - article no . 1015W1001: BA19 must be mounted with attachment screw and mounting bracket (see below) due to the battery weight . Screw M4 countersunk torque 1 .1 Nm +/- 0 .1 Nm . 45°...

  • Page 172: Ba21 Li-Ion

    3. BA21 Li-Ion (MEDLINE CARELINE ® ® The BA21 Li-Ion back-up battery pack has been specially developed for use with the new control boxes COxx and CAxx, e .g . CO61 and CA40, etc . It is a low weight battery with built-in charger and high performance and safety .
  • Page 173 • Disconnect the mains cable to the application • Release the control box off the application • Open the lid to the control box by releasing at the power outlet . by pressing the tab on the mounting clip . the locking clips .
  • Page 174 . If any and all of the lithium ion batteries built into LINAK products are found to be defective under warranty, LINAK will provide a new product to the OEM . LINAK explicitly disclaims all other remedies . LINAK shall not in any event be liable under any circumstances for any special indirect punitive incidental or consequential damages or losses arising from any incident related to the inherent risk of thermal runaway in the lithium ion cell and any use of LINAK products .
  • Page 175 BA21 safety LINAK Li-Ion batteries for medical use are designed and manufactured to be safe through the product life . LINAK has performed various tests of the batteries in normal use, abuse and failure situations to verify the design and production methods . These tests have not shown any unacceptable risks .

  • Page 176: Ccs

    It is not possible to change the cable outlet after the CCM has been manufactured! The bed mounting bracket is not supplied by LINAK, but must be designed and made by the bed manufacturer according to the dimensions below .
  • Page 177 Specifications and requirements: • SIM card type to be used: Mini SIM also called 2FF (it is possible to use SIM adapter for other SIM types which are not delivered by LINAK) . • The SIM card must support voice communication and minimum 2 MB monthly data .
  • Page 178 • If the CCM is offline the data visible on the web portal will not be updated before the CCM is online . • If service is needed from LINAK in relation to a specific person in care, the IMEI number found on the web portal is required .

  • Page 179: Cs16

    • Reconnect castor connection, then OpenBus™ connection, battery power cable, then control box mains . LINAK A/S only delivers the OpenBus™ system and is not responsible for any products other than LINAK products (i .e . products from 3 party suppliers or the compliance of such products with the LINAK OpenBus™ system) .

  • Page 180: Massage Motor Medical

    8. Massage Motor Medical (MEDLINE CARELINE ® ® The massage motor can be added to all kinds of couches and tables, chairs or beds for treatment and examination . It enables comfort, relaxation and tension release for patients and clients . The massage motors are directly connected to the actuator port at the control box –...

  • Page 181: Mjb8

    • The MJB8 is intended for mains operation only . The user must be informed that all MJB8 sensor notifications are disabled when the system is in battery mode . Warnings • LINAK only takes responsibility for LINAK products, not 3 party products . Please pay attention to the “Patient Environment” Clause 3 .79 – EN60601-1 3 edition .

  • Page 182: Simulator Tool

    . Warnings: • The LINAK Simulator Tool is to be used as a test tool or demo tool only . It is not allowed to use the software and accessories as a control in any commercial application .

  • Page 183: Sls

    ® ® LINAK has designed a switch that can be mounted in connection with the 24V DC actuators: LA12, LA22, LA28, LA28S, LA31, LA32, or LA34 and a control box on e .g . a bed frame . The Safety Limit Switch (SLS) . The SLS Switch is primarily used as a Limit Switch in systems consisting of a control box, LA28/28S and/or LA32 .

  • Page 184: Under Bed Light

    Recommendations Please note The SMPS30 is only compatible with LA43 IC and the LA44 IC . The SMPS30 is not suitable for outdoor applications Before installation, re-installation or troubleshooting • Stop the application • Switch off the power supply and pull out the mains plug •...

  • Page 185: Under Bed Light 2

    The WET Detection solution consists of the WET Sheet, the MJB8 and a WET Sheet cable . Recommendations • The WET Sheet is a wearing part which is not covered by the standard LINAK warranty The WET Sheet warranty is valid until the product has been put into use •...

  • Page 186: Qlci2

    Typically the LINAK Weighing Solution will be classified as a “non-automatic weight” system . If a LINAK LINAK Weighing Solution system is applied to a bed AND classified as such, the system MUST be “first-time” verified and sealed . The verification and sealing is typically carried out in one of two ways: 1.
  • Page 187 Mounted on frame: Service lid Integrated hinge Removable if needed Release hook 3-way cable exit Very small built-in dimension: Easy-mount bracket Height: Min . 90 mm (lid can be removed) Length: + 20 mm (locking system) Drawing No .: 1013W4008 Mounting bracket (frame flat) - Mounting bracket (frame flat) w/M4 nuts - Article No .
  • Page 188 Mounting of cables and cable lock: The QLCI2 have a uniquely designed cable lid . The lid also works as an integrated cable lock when closed . 1 . Mount load cell cable plugs in QLCI2 2 . Calibrate the system 3 .
  • Page 189 • It is not allowed to bend load cell cables repeatedly, so mount cables on non-moving parts, like the bed frame . • Load cell cables should not exceed a length of 2700 mm . • In Europe weight systems are subject to important legal restrictions . The LINAK Weighing System system will be approved in accordance with EN45501 .

  • Page 190: Repair And Disposal

    ® authorised LINAK service centre . In order to avoid the risk of malfunction, all actuator repairs must only be carried out by an authorised LINAK Service shop or repairers, as special tools and parts must be used . If a system is opened by unauthorised personel there is a risk that it may malfunction at a later date .
  • Page 191 Page 191 of 192...
  • Page 192 While LINAK uses its best efforts to fulfil orders, LINAK cannot, for the same reasons as mentioned above, guarantee the availability of any particular product . Therefore, LINAK reserves the right to discontinue the sale of any product displayed on its website or listed in its catalogues or other written material drawn up by LINAK .

This manual is also suitable for:

La27La28 compactLa23 medline carelineLa30La31La32 ... Show all

Table of Contents
