Initial Operation
6.4.6

Thickness Measurements

Index Subindex Data type
0x2037
1 16 bytes
Uint8
Uint8
Uint8
Uint8
Float32
Float32
Float32
6.4.7

Thickness Measurement Zero Setting

Index Subindex Data type
0x2038 1 Uint8_t
combiSENSOR KSB6430 PROFINET
Name
Thickness measurement
RW
function
RW Activate
RW Reserved
RW Reserved
RW Reserved
RW e
r
RW Offset
RW Working distance
Name Description
W Thickness Zeroing 1: Activates zero setting
Description
0: Not active
1: Active
Value 0
Value 0
Value 0
Dielectric constant (float > 1)
Offset, in µm of the result (float)
Max. working distance, n µm of the sensor used
Page 31
