Operation

5. Operation
5.1

Initial Operation

Connect the display/output devices via the signal output
switching it on.
i
Let the measuring system warm up for about 15 minutes after applying the supply voltage.
5.2

Controller LEDs

Range
SENSOR
BF
SF
POWER/TRIG.
SIGNAL OUT
KSB6430 DL6435
combiSENSOR KSB6430 PROFINET
socket, see 4.6
LED Color
green
Range
red
BF red
SF red
BF, SF off
before connecting the device to the supply voltage and
Function
Measuring object in measuring range
Measuring range exceeded
Bus failure
System failure
System ok
Page 22
