Installation and Assembly
4.4
Controller
75 (2.95)
BF
SF
POWER/TRIG.
KSB6430
34 (1.34)
Fig. 9 Dimensional drawing of controller with base unit, demodulator and housing cover,
dimensions in mm (inches, rounded off)
combiSENSOR KSB6430 PROFINET
Range
SENSOR
SIGNAL OUT
DL6435
25 (0.98)
8 (0.31)
125 (4.92)
MICRO-EPSILON
Page 17
