Technical Data - MICRO-EPSILON combiSENSOR KSB6430-PROFINET Operating Instructions Manual

Functional Principle, Options, Technical Data
2.3

Technical Data

Controller
Sensor
Target thickness insulator
Working distance
Resolution
Frequency response
Run-out error
Linearity
Temperature stability
Temperature range
Supply voltage
Output
Digital data rate
Trigger
Measuring object
Min. target size
Protection class
Weight
1) Error due to material inhomogeneities in ferromagnetic rollers during roller rotation, depending on material and coating thickness.
combiSENSOR KSB6430 PROFINET
static 100 Hz
dynamic 3.9 kSa/s
Sensor
Controller
Operation Controller: +10 ...+60 °C; Sensor:-10 ...+180 °C; Sensor cable: -10 ...+125 °C
Storage
Analog
PROFINET RT/IRT Capacitive, eddy current and thickness signal, temperature signal: FLOAT
5 µm ... 3 mm
2.5 ... 4 mm (2 ... 5 mm with reduced accuracy)
1 kHz (-3 dB)
< ± 1.5 µm
<±50 ppm/°C (+10 ...+120 °C)
<±50 ppm/°C (in typical measuring range 2,5 ... 4,0 mm)
Sensor, Sensor cable: -10 ... +100 °C, Controller: 0 ... 75 °C
12 ... 36 VDC, typ. 24 VDC (5.5 W)
Capacitive, eddy current and thickness signal,
temperature signal: 0...10 V (short circuit proof)
Internal AD conversion up to 3.906 kSa/s (adjustable via software)
PROFINET RT (down to 1000 µs)
PROFINET IRT (down to 500 µs)
Straight surface or min. diameter 200 mm
Coating, e.g., Chrome, at least 150 µm
Sensor: IP54, controller: IP 40
Sensor: 80 g; controller: 750 g
KSB6430
KSH5(03)
0.0004 %
0.0015 %
1
±0,05 %
TTL, 5 V
2
ø45 mm
