4.2.12 Power supply

4.2.12.1 5AC902.PS00-00

4.2.12.1.1 General information

This AC power supply for the Panel PC can optionally be expanded to allow operation with 100~240 VAC.
4.2.12.1.2 Order data
Order number Short description
Power supply unit
5AC902.PS00-00 PPC900 power supply 85-264 VAC
Required accessories
Terminal blocks
0TB3103.8000 Connector 230 VAC - 3-pin female - Screw clamp terminal block
4 mm² - Protected against vibration by the screw flange
4.2.12.1.3 Technical data
Order number
General information
Power button
Certifications
CE
UL
HazLoc
EAC
Input
Nominal input voltage
Frequency
Inrush current
Power failure bypass
Internal fuse
Output
Nominal voltage
Output current
0 to 55°C
Electrical properties
Overvoltage category per EN 61131-2
Mechanical properties
Housing
Material
Coating
Dimensions
Width
Height
Depth
Weight
1) Yes, but applies only if all components installed in the complete system have this certification and the complete system bears the corresponding mark.
2) IEC 61010-2-201 requirements must be observed; see section "+24 VDC power supply" in the user's manual.
3) At an ambient temperature of 0 to 55°C and nominal voltage.
4.2.12.1.4 Installation
For information about installing this power supply, please refer to the section
supply" on page 212.
Panel PC 900 (Skylake) User's manual V 1.10
Table 133: 5AC902.PS00-00 - Order data
<20 A (on cold restart, 100% load and 100 VAC)
Table 134: 5AC902.PS00-00 - Technical data
5AC902.PS00-00
Yes
Yes
cULus E115267
Industrial control equipment
cULus HazLoc E180196
Industrial control equipment
for hazardous locations
Class I, Division 2, Groups ABCD, T3C
Yes
100 to 240 VAC
45 to 65 Hz
>10 ms (100 VAC and 230 VAC)
Yes
24 VDC ±10%
2)
5.5 A
3)
II
Steel sheet
Anthracite
73.5 mm
225.5 mm
53.5 mm
580 g
"Installing or replacing the AC power
Technical data
Figure
1)
201
