Installation and wiring
5.1.7.4 Installing the interface option
1. Disconnect the power supply to the B&R Industrial PC (disconnect the power cable). Isolate the system from
all potential sources of electrical power!
2. Touch the housing or ground connection in order to discharge any electrostatic charge from your body.
Information:
If a bus unit is mounted on the Panel PC, it must be removed first.
3. Remove the Torx screws (T10) indicated by ➀ in the following image. The Torx screws indicated by ➁ only
need to be removed if an IF option is already mounted.
4. Lift the cover plate up and away to remove it.
216
Panel PC 900 (Skylake) User's manual V 1.10
