Order number
Interfaces
USB
Quantity
Type
Variant
Transfer rate
Current-carrying capacity
Keys
Function keys
System keys
Service life
LED luminous intensity
Yellow
Operating conditions
Pollution degree per EN 61131-2
Degree of protection per EN 60529
Degree of protection per UL 50
Mechanical properties
Front
4)
Frame
Panel overlay
Material
Light background color
Dark border color around display
Gasket
Dimensions
Width
Height
Weight
1) Yes, but applies only if all components installed in the complete system have this certification and the complete system bears the corresponding mark.
2) At 25°C ambient temperature. Reducing the brightness by 50% can increase the half-brightness time by approximately 50%.
3) Touch screen drivers for approved operating systems are available for download in the Downloads section of the B&R website (www.br-automation.com).
4) Visual deviations in color and surface quality are possible due to process or batch conditions.
4.2.2.3.4 Dimensions
Panel PC 900 (Skylake) User's manual V 1.10
5AP1181.1043-000
USB 2.0
Type A
Low speed (1.5 Mbit/s), full speed (12 Mbit/s) to high speed (480 Mbit/s)
Max. 500 mA
38 with LED (yellow)
Numeric keys, cursor block
>1,000,000 actuations at 1 ±0.3 N to 3 ±0.3 N actuating force
Typ. 38 mcd
Pollution degree 2
Front: IP65
Back: IP20 (only with installed link module or installed system unit)
Front: Type 4X indoor use only
Aluminum, naturally anodized
Polyester
RAL 9006
RAL 7024
3 mm fixed gasket
323 mm
358 mm
3400 g
323
Technical data
1
