For Installer: Mounting Via Connect² - Kramer VIA Connect2 User Manual

For Installer: Mounting VIA
Connect²
This section provides instructions for mounting
environment is within the recommended range:
• Operation temperature – 0° to 40°C (32 to 104°F).
• Storage temperature – -40° to +70°C (-40 to +158°F).
• Humidity – 10% to 90%, RHL non-condensing.
Caution:
• Mount VIA Connect²
• The device is intended to be installed at a height of 2 meters or less.
Warning:
• Ensure that the environment (e.g., maximum ambient temperature & air flow) is compatible for
the device.
• Avoid uneven mechanical loading.
• Appropriate consideration of equipment nameplate ratings should be used for avoiding
overloading of the circuits.
• Reliable earthing of rack-mounted equipment should be maintained.
You can install VIA Connect²
• Place the device on a flat surface.
Mount on a wall or the back of a display using the included VESA mounting bracket:
•
1. Attach the VESA mounting bracket
to the back of the display with 4
screws.
When mounting the device on a display, the installer MUST secure the display to prevent
instability.
VIA Connect² – For Installer: Mounting VIA Connect²
before connecting any cables or power.
using one of the following methods:
2. Fasten two screws to the bottom
of VIA Connect².
VIA Connect². Before installing, verify that the
Kramer Electronics Ltd.
3. Insert the screws on the
bottom of VIA Connect²
into the slots on the
mounting bracket.
