Kramer VIA Campus2 Quick Start Manual

Hide thumbs Also See for VIA Campus2:
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual
Scan for full manual
Step 1: Check what's in the box
VIA
Campus² collaboration device
Step 2: Get to know your VIA Campus²
#
Feature
1
Power Button
2
USB 2.0 Connector
3
DC IN 19V Connector
4
Wi-Fi Antenna Port (1 of 2)
5
HDMI OUT Connector
6
HDMI IN Connector
7
DP OUT Connector
8
USB 2.0 Connectors
9
LAN RJ-45 Connector
10
USB 3.2 Connectors
11
AUDIO MIC IN 3.5mm Mini Jack
12
Wi-Fi Antenna Port (2 of 2)
13
AUDIO LINE OUT 3.5mm Mini Jack Connect to an unbalanced stereo audio acceptor.
14
REMOTE 2-pin Terminal Block
VIA Campus² Quick Start
VIA Campus² Quick Start Guide
For Installer
This guide helps you install and configure your
www.kramerav.com/product/VIA Campus
Go to
upgrades are available.
1 Power adapter (19V DC)
Function
For turning the unit on and off.
Connect to a USB device.
Connects to the 19V DC power adapter.
Connect one of the Wi-Fi antennas for collaborating via the built-in Wi-Fi.
Connect to an HDMI display.
Connect to an HDMI source (for example a laptop).
Connect to a DisplayPort display.
Connect to up to 2 USB devices.
Connect a Local Area Network (LAN) cable.
Connect to up to 2 USB devices.
Connect to a microphone.
Connect one of the Wi-Fi antennas for collaborating via the built-in Wi-Fi.
Connect to a toggle switch to remotely turn the device on and off.
VIA
Campus² for the first time.
2
to download the latest user manual and check if firmware
2 Wi-Fi antennas
P/N: 2 9 0 0 - 3 0 1 6 4 5 QS
1 Quick start guide
Rev: 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VIA Campus2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kramer VIA Campus2

Summary of Contents for Kramer VIA Campus2

  • Page 1 VIA Campus² Quick Start Guide For Installer This guide helps you install and configure your Campus² for the first time. www.kramerav.com/product/VIA Campus Go to to download the latest user manual and check if firmware Scan for full manual upgrades are available. Step 1: Check what’s in the box Campus²...
  • Page 2 The device is intended to be installed at a height of 2 meters or less. Warning: Use only the Kramer Electronics power adapter that is provided with the unit. Warning: Disconnect the power and unplug the unit from the wall before installing.
  • Page 3 VIA app. The driver only needs to be installed once and can also be downloaded from the VIA app. For iOS or Android devices: Download and install the free Kramer VIA app from the Apple App Store or Google Play.
  • Page 4 Step 4: Using the VIA dashboard menu VIA Dashboard For more information see “Presenting from the VIA User Dashboard” in the User Manual. 1. Select what you want to share: ▪ Screen – Share your screen. On Windows the down arrow adds the Main display as a second screen.
