Kramer VIA Connect2 User Manual page 105

The name of your device appears on the main display and then your screen is mirrored
on the main display.
Mirroring Android Devices Using Miracast
To mirror an Android device using Miracast:
1. In your Android device settings, open WiFi Direct, Miracast, or ScreenCast.
Device options appear on your screen.
2. Click the Room Name of your VIA collaboration device.
A PIN code field appears (if Code was activated on your VIA device).
3. Enter the Code that appears on the main display and click Accept/Connect.
The name of your device appears on the main display and then your screen is mirrored
on the main display.
Presenting with Extended Desktop
VIA Connect² can be setup to add
desktop. The user's primary screen is not shared, allowing the user to keep their laptop
display private while sharing.
This feature is available on Windows client laptops only, after installation of the required
drivers. When using this feature for the first time, the system asks you to install the drivers.
Please accept and follow the on-screen instructions. Once the drivers are installed, reboot
your PC to enable the feature.
Mac users can use AirPlay to simulate the same behavior.
To mirror with the Extended Desktop feature:
On the Kramer VIA User Dashboard, click the Screen-1 icon and select Extended.
•
An extension of your device desktop appears on the VIA main display.
Drag content to the left and beyond your primary screen to show it on the main display.
•
You can change the relative positioning of the two displays in your device
Control Panel under Screen Resolution.
VIA Connect² – For User: Connecting via VIA Connect²
the main display as an extension of the user's device
Figure 119: Media Player Window
