Scan for full manual
Step 1: Check what's in the box
VIA
Connect² Collaboration Device
1 Power supply (12V DC) with adapters for US, UK, and EU
Step 2: Get to know your VIA Connect²
#
Feature
1
Video Toggle Connector
2
Micro SD Card Slot
3
Power Button with LED
4
USB 3.0 Connectors (x2)
5
USB 2.0 Connector
6
Lock Opening
7
HDMI™ OUT Connector
8
RJ-45 Connector
9
HDMI™ IN Connector
10
Power Connector
Step 3: Mount VIA Connect²
Place
VIA
Connect² on a flat surface, or mount on a wall or the back of a display using the included VESA mounting bracket:
1. Attach the VESA mounting bracket to
the back of the display with 4 screws.
When mounting the device on a display, the installer MUST secure the display to prevent instability.
VIA Connect² Quick Start
VIA Connect² Quick Start Guide
For Installer
This guide helps you install and use your
Go to
www.kramerav.com/downloads/VIA Connect²
firmware upgrades are available.
Function
Connect to video toggle cable for toggling between VIA input and HDMI™ input.
Not in use.
Press to power ON or turn OFF the device.
Connect to USB devices, for example, a keyboard and a mouse.
Connect to a USB device, for example, a keyboard or mouse.
Connect to a security locking cable.
Connect to an HDMI sink.
Connect to a LAN (default mode).
Connect to an HDMI source.
Connect to the 12V DC power supply.
2. Fasten two screws to the bottom of
VIA
Connect².
VIA
Connect² for the first time.
to download the latest user manual and check if
1 VESA mounting bracket
1 VESA screw set
3. Insert the screws on the bottom of
VIA
Connect² into the slots on the
mounting bracket.
P/N: 2 9 0 0 - 3 0 1 6 2 6 QS
1 Quick start guide
1 Video toggle cable
Rev: 4
Advertisement
Table of Contents
Related Manuals for Kramer VIA Connect2
Summary of Contents for Kramer VIA Connect2
- Page 1 VIA Connect² Quick Start Guide For Installer This guide helps you install and use your Connect² for the first time. Go to www.kramerav.com/downloads/VIA Connect² to download the latest user manual and check if firmware upgrades are available. Scan for full manual Step 1: Check what’s in the box Connect²...
- Page 2 The device is intended to be installed at a height of 2 meters or less. Warning: Use only the Kramer Electronics power adapter that is provided with the unit. Warning: Disconnect the power and unplug the unit from the wall before installing.
- Page 3 Connect² appears. Click Run VIA to execute the Kramer VIA app without downloading it. For guests who are using VIA temporarily. OR Click Install VIA to download the Kramer VIA app onto your computer. For regular users of the VIA.
- Page 4 Step 4: Using the VIA dashboard menu For more information see “Presenting from the VIA User Dashboard” in the User Manual. 1. Select what you want to share: ▪ Screen – Share your screen. ▪ App – Share a window or a third party app. ▪...
