Step 1: Check what's in the box
VIA
Campus² Collaboration Device
1 Power supply (12V DC) with adapters for US, UK, and EU
Step 2: Get to know your VIA Campus²
#
Feature
1
Power Button
2
USB 2.0 Connector
3
DC IN 19V Connector
4
Wi-Fi Antenna Port (1 of 2)
5
HDMI OUT Connector
6
DP OUT Connector
7
USB 3.0 connectors
8
USB 2.0 connectors
9
LAN RJ-45 Connector
10
Wi-Fi Antenna Port (2 of 2)
11
REMOTE 2-pin Terminal Block
LINE OUT 3.5mm Mini Jack Connect to an unbalanced stereo audio acceptor.
12
AUDIO
MIC IN 3.5mm Mini Jack
Step 3: Mount VIA Campus²
Install VIA Campus² using one of the following methods:
•
Mount the unit in a rack using the recommended rack adapter
(see
www.kramerav.com/product/VIA Campus
•
Place the device on a flat surface.
VIA Campus² Quick Start
VIA Campus² Quick Start Guide
For Installer
This guide helps you install and configure your
Go to
www.kramerav.com/downloads/VIA Campus²
firmware upgrades are available.
Function
For turning the unit on and off.
For upgrading firmware or connecting a USB device.
Connects to the 19V DC power adapter.
Connect one of the Wi-Fi antennas for collaborating via the built-in Wi-Fi.
Connect to an HDMI display.
Connect to a DisplayPort display.
Connect to up to 2 USB devices.
Connect to up to 2 USB devices.
Connect a Local Area Network (LAN) cable.
Connect one of the Wi-Fi antennas for collaborating via the built-in Wi-Fi.
Connect to a toggle switch to remotely turn the device on and off.
Connect to a microphone.
2
).
VIA
Campus² for the first time.
to download the latest user manual and check if
1 VESA mounting bracket
1 VESA screw set
Ensure that the environment (e.g., maximum ambient temperature & air
flow) is compatible for the device.
Avoid uneven mechanical loading.
Appropriate consideration of equipment nameplate ratings should be
used for avoiding overloading of the circuits.
Reliable earthing of rack-mounted equipment should be maintained.
P/N: 2 9 0 0 - 3 0 1 6 2 7 QS
1 Quick start guide
1 Video toggle cable
Rev: 2
Advertisement
Table of Contents
Related Manuals for Kramer VIA Campus2
Summary of Contents for Kramer VIA Campus2
- Page 1 VIA Campus² Quick Start Guide For Installer This guide helps you install and configure your Campus² for the first time. Go to www.kramerav.com/downloads/VIA Campus² to download the latest user manual and check if firmware upgrades are available. Scan for full manual Step 1: Check what’s in the box Campus²...
- Page 2 The device is intended to be installed at a height of 2 meters or less. Warning: Use only the Kramer Electronics power adapter that is provided with the unit. Warning: Disconnect the power and unplug the unit from the wall before installing.
- Page 3 OR Click Install VIA to download the Kramer VIA app onto your computer. For regular users of the VIA. For iOS or Android devices: Download and install the free Kramer VIA app from Apple App Store or Google Play. For Chromebook or Chrome Browser: Click Join through browser on the Welcome page.
- Page 4 Step 4: Using the VIA dashboard menu For more information see “Presenting from the VIA User Dashboard” in the User Manual. 1. Select what you want to share: ▪ Screen – Share your screen. ▪ App – Share a window or app that you are using. ▪...
