CCL-WB2MC-SMART-TRI INSTALLATION MANUAL
2.3

SPACE REQUIREMENTS

When installing the equipment respect minimum distances space for maintenance
and safety reasons.
Both cable holders (supplied) must be installed under the charge point. Take into
account the required space during the installation.
Height y recommended is between 0,6m and 1,2m. Please comply accordingly to your
country specifications.
Units specified in mm
