CCL-WB2MC-SMART-TRI

4 PRODUCT OVERVIEW

6
1. Liquid Cristal Display
4. RFID Reader
7. Cable holder
.
1
4
5
2. Plug A - Status beacon 3. Plug B - Status beacon
5. Front cover
INSTALLATION MANUAL
2
3
7
6. Type 2 tethered cable
8
© CIRCONTROL
www.circontrol.com
