Electrical Wiring Considerations - Circontrol WALLBOX SMART Series Installation Manual

CCL-WB2MC-SMART-TRI
2.2

ELECTRICAL WIRING CONSIDERATIONS

1. Charge point – Input power supply
Charge point does not include elements of electrical protection.
The input power supply line must be hardwired from a distribution board to the charge
point under electrical safety regulations according to your country regulations. Minimum
safety required protections:
- RCD: Type A. I
- MCB: maximum value according to the maximum output current of the
charge point. Refer to TECHNICAL DATA section for further information.
2. Power supply Line dimensioning
The dimensioning of the input power supply line of the charge point must be checked
by a qualified electrician. Note that various factors such as cable length between
distribution board and charge point, maximum output current of the charge point may
have influence of the selected cable.
In such cases, increasing the cable cross-section it is required to adapt the
temperature resistance of the power supply line.
3. Charge point – Maximum current output
If the power supply is less than maximum output current of the charge point, and
adjustment to a lower nominal current must be performed. Please refer to
ADDITIONAL SETTINGS section in order to know how to change this value.
Please refer to the TECHNICAL DATA section to consult the default factory settings
from maximum output current of the charge point. Depending of the model this value
may vary.
Before start with the wiring connection of the charge point
shall take in consideration this section.
=0.03A.
ΔN
INSTALLATION MANUAL
4
