CCL-WB2MC-SMART-TRI

10 TECHNICAL DATA

AC INPUT
AC Power supply
AC Voltage
Nominal input current
Nominal input power
Frequency
OUTPUT
Charge system
Sockets/ Plugs
Maximum output power
Maximum output current
Output voltage range
ENERGY METERS
Accuracy class in active energy
Meter standards
NETWORK
Ethernet
GENERAL
Enclosure rating
Enclosure material
Operating temperature
Operating humidity
RFID system
Display
Power limit control
Interface protocol
Net weight
CCL-WB2MC-SMART-TRI
PLUG A
22kW
32A
EN62052-11, EN62053-21, EN62053-23, EN61010-1
To 95% RH Non-condensing
LCD Backlight double line text
Mode 3 PWM control according ISO / IEC 61851-1
28
INSTALLATION MANUAL
3P + N + PE
400V +/- 10%
AC
32A + 32A
22kW + 22kW
50 / 60 Hz
PLUG B
Mode 3
Type 2 Tethered cable
22kW
32A
400V (3P + N + PE)
AC
Class 1 (IEC 62053-21)
10/100BaseTX
IP54 / IK10
ABS
-10 to +45ºC
ISO / IEC14443A / B
OCPP / XML
7Kg
