9 ADDITIONAL SETTINGS

9.1

CHANGE MAX. CURRENT OF PLUG

If the power supply is less than the maximum output current of the charge point, use
Charge Point Setup tool in order to set a lower current rating.
Download it from:
1.
Procedure
1- Set the IP address from the Charge Point (IP address must have been
previously assigned using IPSetup)
2- Click under Connect button.
3- Select the desired plugs to set a new current value. By default, all plugs are
selected.
4- Set the new current value to apply on each plug.
5- Click under Apply settings button and wait until the process ends.
http://www.circontrol.com/downloads/
