Component Parts Location - Circontrol WALLBOX SMART Series Installation Manual

CCL-WB2MC-SMART-TRI

5 COMPONENT PARTS LOCATION

1
8
1. CCL1-Mini Device
4. Plug A – Meter
7. Plug B – Meter
10. Plug A – AC terminals 11. Plug B – Contactor
13. Plug B – LED beacon
2 3
9 10
2. Cellular modem
5. Plug A – Mode 3
8. Plug A – LED beacon
INSTALLATION MANUAL
4 5 6
11 12
3. 12V
6. Plug B – Mode 3
9. Plug A – Contactor
12. Plug B – AC terminals
9
7
13
Power Supply
DC
