2 INSTALLATION GUIDELINES

2.1

IMPORTANT SAFETY INSTRUCTIONS

The charge point is designed for installation in indoor and outdoor areas. For each of
the different conditions of installation, the unit must be installed safely and ensure
adequate protection.

Charge point must not be installed in areas where there is potential risk
of explosions.

Do not install the charge point where falling objects may damage the
equipment.

Wall surface where the charge point is placed must withstand the
mechanical forces.

Do not use this unit for anything other than electric vehicle charging
modes are expected in IEC 61851.

Do not modify this unit. If modified, CIRCONTROL will reject all
responsibility and the warranty will be void.

Comply strictly with electrical safety regulations according to your
country.

Do not make repairs or manipulations with the unit energised.

Only trained and qualified personnel should have access to low-
voltage electrical parts inside the device.

Check the installation annually by qualified technician.

Remove from service any item that has a fault that could be dangerous
for users (broken plugs, caps that don't close...).

Use only Circontrol supplied spare parts.

Do not use this product if the enclosure or the EV connector is broken,
cracked, open, or shows any other indication of damage.
Refer to TECHNICAL DATA section for more information about environment
installation conditions.
Read carefully all the instructions before starting to
ensure properly installation of the charge point.
