characteristics
Characteristic Description
Differential signal range (DC
coupling)
operating voltage
window
Differential offset range
maximum non-destructive
Type P7380A, Type
1
input voltage
1
See note below
ATTENTION: To avoid damaging the probe, do not allow peak
voltages on the differential inputs to exceed 15V pk with respect to
ground.
P7360A, Type P7340A ± 1
V (5X)
± 2.5 V （25X）
Model P7313
± 0.625 V （5X）
± 2.0 V （25X）
P7380A, P7360A, P7340A
-3.0 to +5.0 V (5X and 25X)
Model P7313
-3.0 to +4.0 V (5X and 25X)
-3.0 to +4.0 V
± 15 V between each input or between the probe
input and ground
(DC + peak AC)
