Figure 16: Securing the Handheld Adapter
Note : When the handheld adapter is properly assembled, an
elastomeric pad on the nose of the handheld adapter (see Figure 15)
applies pressure to the probe tip. The pressure will be evenly
distributed as long as it is not too large. Even pressure distribution
across the probe tip makes it easier to connect two interconnect
points for differential measurements.
22 Z-Active Differential Probe Family User Manual
Removing the Handheld Adapter Housing
Notice : To avoid damaging the handheld adapter when removing it
from the probe, first slide the latch on the upper housing and then
separate the housing. Sai.
