Figure 12: TDS/CSA8X00 Series Sampling
oscilloscope
Note : For proper operation, you must use 80A03 firmware version
2.0 or later. The firmware version label is located on the rear panel of
the 80A03 instrument.
Basic operations
HBW Soldering Tip-Clip requires full bandwidth measurements using
the P7313 probe. HBW Tip-The Clip is designed with a damping
resistor attached to the cord circuit and a circuit attachment wire
soldered to the end of the damping resistor (see Figure 13). ).
Z-Active Differential Probe Family User Manual 17
Soldered HBW Tip- Clip assembly (P7313 only)
