Tektronix Z-Active Series User Manual page 53

P7313 -
P7380A 3
P7360A 2
P7340A 2
P7313 -
P7380A 3
P7360A -
P7340A -
38 Z-Active Differential Probe Family User Manual
Table 3: Standard accessories (continued)
additional order
(Our part number)
Medium length cord, 1/8
W tip with large resistor-
Clip assembly.
Bandwidth: >8.0 GHz
(P7380A) T : 10/90 <55
R
ps、20/80 <35 ps Load ：
260 Oh ～ 8 GHz
Z
MIN
Bandwidth: >5.0 GHz
(P7360A) T ： 10/90 <70
R
ps、20/80 <50 ps load ：
Z 260 Ω ～ 6 GHz
MIN
Bandwidth: >4.0 GHz
(P7340A) T ： 10/90
R
<100 ps、20/80 <75 ps
load ： Z 260 Ω ～ 4
MIN
GHz
Suitable for providing
ease of use and best
performance in equal
measure when installed in
larger devices.
020- 2603- XX (10 kits)
1/8 W Tip with long cord
and large resistor- Clip
assembly.
Bandwidth: >7.0 GHz
(P7380A) T : 10/90 <75
R
ps、 20/80 <40 ps Load ：
300 Oh ～ 8 GHz
Z
MIN
It is an assembly with
good step response and
wide reach. Useful for
connecting circuits of
large mechanisms in
hard-to-reach locations.
You can adjust the size
to fit the width between
DIMM modules. Not
recommended for signals
faster than 4 GHz.
020- 2605- XX (10 kits)
accessories
