Connecting the P7000 probe to the TDS8000
sampling oscilloscope
④ Connect to one of the channels of the 80A03 and probe the source
clock that provides a trigger signal in synchronization with the
signal you want to measure. See Figure 21.
④ Connect a cable between the TekConnect socket output connector
of the trigger signal you want to probe and the external trigger
input of the sampling oscilloscope.
④ Probe the synchronous data signal you want to measure on the
other channels of the 80A03.
Figure 21: TDS8000 sampling oscilloscope
