POWER Type
Connector
Consumption
RTC Battery
OS SUPPORT Microsoft
Linux
ENVIRONMENT Temperature
Humidity
MTBF
MECHANISM Dimensions
Height
STANDARDS AND CERTIFICATIONS Certifications
User's Manual | RPS101_RPS103
RPS101: Single 12V +/-10% DC
RPS103: Wide Range 12~28V
DC-in Jack
Right Angle Connector (4-pin) (available upon request)
Straight Type Connector (4-pin) (available upon request)
TBD
CR2032 Coin Cell
Windows 10 IoT Enterprise 64-bit
Windows 11 Enterprise
Linux
Operating: -5 to 65°C
Storage: -40 to 85°C
Operating: 5 to 90% RH
Storage: 5 to 90% RH
TBD
Mini-ITX Form Factor: 170mm (6.7") x 170mm (6.7")
Top Side: 19mm
Bottom Side: 4.5mm
CE, FCC Class B, RoHS
