SYSTEM
Processor
12th Generation Intel® LGA 1700 Socket Processors, TDP support up to 65W
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Chipset
Intel
Memory
Two 262-pin SODIMM up to 64GB
Dual Channel DDR5 4800 MHz (ECC support: R680E only)
BIOS
AMI SPI 256Mbit
GRAPHICS
Controller
Intel
Feature
3D graphics HW acceleration:DX12, Open GL 4.6, Vulkan 1.2
HW Video Decode:
8K60 12b 4:2:0 HEVC/VP9/SCC
8K30 10b 4:2:0 AV1
5K60 10b 4:4:4 HEVC/VP9/SCC
4K60 8b 4:2:0 AVC
HW Video Encode:
8K30 or 5K60 8b/10b 4:2:0 HEVC/VP9/SCC
4K60 10b 4:4:4 HEVC/VP9/SCC
4K60 8b 4:2:0 AVC
Display
1 x HDMI 2.0
HDMI: resolution up to 4096x2160 @ 60Hz
1 x DP++ 1.2
DP++: resolution up to 4096x2304 @ 60Hz
1 x USB Type-C(H610E not support)
USB Type C: resolution up to 4096x2304 @ 60Hz
1 x eDP/LVDS
eDP: resolution up to 4096x2160 @ 60Hz
LVDS: resolution up to 1920x1200 @ 60Hz
1 x DFI display extension port (DP/HDMI/VGA available)
Quad Displays
DP++ + HDMI + LVDS/eDP +USB Type C +DFI display extension port (DP/HDMI/VGA available)
User's Manual | RPS101_RPS103
Core™ i9-12900E (16 Cores, 30M Cache, up to 5.0 GHz); 65W
®
Core™ i9-12900TE (16 Cores, 30M Cache, up to 4.8 GHz); 35W
®
Core™ i9-12900(16 Cores, 30M Cache, up to 5.0 GHz); 65W
®
Core™ i7-12700E (12 Cores, 25M Cache, up to 4.8 GHz); 65W
®
Core™ i7-12700TE (12 Cores, 25M Cache, up to 4.7 GHz); 35W
®
Core™ i7-12700 (12 Cores, 25M Cache, up to 4.8 GHz); 65W
®
Core™ i5-12500E (6 Cores, 18M Cache, up to 4.5 GHz); 65W
®
Core™ i5-12500TE (6 Cores, 18M Cache, up to 4.3 GHz); 35W
®
Core™ i5-12500 (6 Cores, 18M Cache, up to 4.6 GHz); 65W
®
Core™ i5-12400 (6 Cores, 18M Cache, up to 4.4 GHz); 65W
®
Core™ i3-12100E (4 Cores, 12M Cache, up to 4.2 GHz); 60W
®
Core™ i3-12100TE (4 Cores, 12M Cache, up to 4.0 GHz); 35W
®
Core™ i3-12100 (4 Cores, 12M Cache, up to 4.3 GHz); 60W
®
G7400E (2 Cores, 6M Cache, 3.6 GHz); 46W
®
G7400TE (2 Cores, 6M Cache, 3.0 GHz); 35W
®
G6900E (2 Cores, 4M Cache, 3.0 GHz); 46W
®
G6900TE (2 Cores, 4M Cache, 2.4 GHz); 35W
®
R680E/Q670E/H610E Chipset
®
UHD Graphics 700 series
®
Chapter 1
INTRODUCTION
7
