Ddi (J19) - DFI RPS101 User Manual

DDI (J19)

1 2
9 10
1
10
2
9
1
10 9
2 1
20
19
19 20
1 2
1
2
User's Manual | RPS101_RPS103
1
2 10
1
2 10
1
1
1
1
1 2
11
1
1
1 1
1 2
1
1
1 2
1
14
5 6
10
1
39 1
2
40
1
HARDWARE INSTALLATION
Pin Assignment Pin Assignment
1 2
DDI5_TX1N DDI5_TX2N
3 4
DDI5_TX1P DDI5_TX2P
5 GND 6 GND
7 DDI5_TX0P 8 DDI5_TX3N
9 10
DDI5_TX0N DDI5_TX3P
11 GND 12 GND
13 DDI5_AUXP 14 CLK
15 16
DDI5_AUXN DATA
17 GND 18 PCH_SYSPWROK
19 Hot Plug Detect 20 DP_PWR
Chapter 2
21
