DFI RPS101 User Manual page 12

DC-in
2.5G LAN 1
2.5G LAN 2
USB3.2 Gen2
R680E/Q670E - USB3.2 Gen2
H610E - USB2.0
R680E/Q670E -
▲ USB3.2 Gen2 ▼USB Type-C
H610E -
▲ USB3.2 Gen1
▲DP++
▼HDMI2.0
Front Audio
USB2_10/11
USB2_5/6
COM2
COM1
PCIE1
DDI
Clear CMOS/Clear CMOS button (Pin Header option)
* Press and hold the "CMOS" button for 5-10 seconds
System Fan
Buzzer
SPI
Front Panel
SATA1 (R5)
User's Manual | RPS101_RPS103
SATA1 (R4)
SATA Power Connector
eSPI Connector
DIO Connector
LCD Panel Power Supply
LVDS LCD Inverter Connector
LVDS LCD Panel Power Supply
LCD Inverter Power
LVDS
CPU Fan
SATA Power Connector
SMBUS & I2C Header
OOB SPI Header
OOB I2C Header
SIM Card Slot
eDP
Chapter 2
HARDWARE INSTALLATION
12
