DFI RPS101 User Manual page 8

EXPANSION Interface
AUDIO Audio Codec
ETHERNET Controller
REAR I/O Ethernet
USB
Display
INTERNAL I/O Serial
USB
Display
Audio
SATA
SMBus
DIO
WATCHDOG TIMER Output & Interval
SECURITY TPM
User's Manual | RPS101_RPS103
1 x PCIe x16 (Gen 5) (Max. 75W)
1 x M.2 2230 E Key (USB 2.0x1/CNVix1/PCIe3.0 x1)
R680E/Q670E:
1 x M.2 2242/3042/3052 B Key (PCIe 3.0 x1/SATA 3.0x1/USB 3.2 Gen2x1/USB 2.0x1)
1 x M.2 2280 M Key (PCIe 4.0x4 or SATA 3.0x1)
H610E:
1 x M.2 2242/3042/3052 B Key (PCIe 3.0x1/SATA3.0x1/USB 3.2 Gen1x1/USB 2.0x1)
1 x M.2 2280 M Key (PCIe 3.0x1/SATA3.0x1)
Realtek ALC888
1 x Intel I226-LM (Core i9/i7/i5 support iAMT)
®
1 x Intel I226-V
®
2 x Intel I226-V (only H610E support)
®
2 x 2.5GbE (RJ-45)
R680E/Q670E:
5 x USB 3.2 Gen 2 Type A
1 x USB 3.2 Gen 2 USB Type C
H610E:
2 x USB 3.2 Gen 2
1 x USB 3.2 Gen 1
2 x USB 2.0
1 x HDMI 2.0
1 x DP++ 1.2
1 x USB Type-C ( H610E not supported )
2 x RS-232/422/485 (w/o Power) Box header (2.0mm pitch)
R680E/Q670E:
4 x USB 2.0 (2 2x5 2.0mm pitch header)
H610E:
2 x USB 2.0 (1 2x5 2.0mm pitch header)
1 x eDP/LVDS
1 x DFI display extension port (DP/HDMI/VGA available)
1 x Front Audio Header (1 x Line-out, 1 x Mic-in)
2 x SATA 3.0 (up to 6Gb/s)
2 x SATA Power
RAID 0/1/5/10 (w/ M.2 Key-M/B slot + 2 SATA Conn.)
1 x SMBus
1 x 8-bit DIO
System Reset, Programmable via Software from 1 to 255 Seconds
Nuvoton TPM 2.0
Chapter 1
INTRODUCTION
8
