2.1 Short description
• Semi-hermetic four-cylinder reciprocating compressor with oil pump lubrication.
• Lightweight aluminum design
• Suction gas-cooled drive motor
Transport eyelet
Discharge
shut-off valve
Oil pump
D
GB
F
E
Terminal box
Suction
shut-off valve
Dimension and connection values can be found in Chapter 9
6 | AQ464037893946en-IN0201
Fig. 1
Fig. 2
© Danfoss | Climate Solutions | 2024.07
Name plate
Oil sightglass
Cylinder cover
Valve plate
Drive motor
Motor part
