Type Key - Danfoss BOCK HGX34e A Operating Manual

2 | Product description
2.2 Name plate (example)
BOCK
HGX34e/380-4 SA
1
2
AT38125A028
3
31,2/18,0A
4
132A
5
Fig. 3
1 Type designation
2 Machine number
3 maximum operating current
4 Starting current (rotor blocked)
5 ND LP: max. admissible operating pressure 10 Nominal rotation speed
Low pressure side
HD (HP): max. admissible operating
pressure . High pressure side
Observe the limits of application
diagrams!
2.3 Type key (example)
HG X 3 e 380-4 S A 4
) HG - Hermetic Gas-cooled (suction gas-cooled)
¹
) X - Ester oil charge (HFC refrigerant, e.g. R134a, R404A, R507, R407C)
²
)
3 S - More powerful motor, e.g. for air-conditioning applications
© Danfoss | Climate Solutions | 2024.07
76A
19/28
/
IP66
6 Voltage, circuit, frequency
7 Nominal rotation speed
8 Displacement
9 Voltage, circuit, frequency
11 Displacement
12 Oil type filled at the factory
13 Protection system terminal box
Electrical accessories can change
the IP protection class!
Lightweight aluminum design
Motor variant
Number of poles
Swept volume
e = e-series / P = Pluscom
Numbers of cylinders
Size
Oil charge ²
)
Series ¹
AQ464037893946en-IN0201 | 7
