5| Electrical connection
5.2 Connection of the driving motor
The compressor is designed with a motor for star-delta circuits.
Designation on the name plate
∆ / Y
Star-delta start-up is only possible in the ∆ voltage range. Example:
Direct start
L1 L2
L3
INFO!
© Danfoss | Climate Solutions | 2024.07
230 V ∆
Star-delta start
L1 L2
L1 L2
The connection examples shown refer to the standard
version. In the case of special voltages, the instructions affixed to the
terminal box apply.
Direct start only
L3
L3
AQ464037893946en-IN0201 | 15
400 V Y
L1 L2
L3
D
GB
F
E
