3| Product description

• HG44e: Semi-hermetic four-cylinder reciprocating compressor with suction-gas cooled drive motor.

• HG56e: Semi-hermetic six-cylinder reciprocating compressor with suction-gas cooled drive motor.

• Preferred application range: normal refrigerating and air-conditioning.

Transport eyelet

Valve plate

Oil pump

Fig. 1

Suction

shut-off valve

Fig. 2

Dimension and connection values can be found in Chapter 12

Terminal box

Name plate

Oil sight glass

HG44e

Discharge

shut-off valve

Drive section

Motor section

HG56e

AQ452044031215en-000201 | 7

Cylinder

cover
